6-8. Printed Wiring Board – BD (SIDE B) Board –
• See page 54 for Circuit Boards Location.
IC190
IC141
IC151
IC153
IC102
IC101
IC181
IC195
DIGITAL
BOARD
(Page 79)
DIGITAL
BOARD
(Page 79)
D
C
1
3
4
E
5
S102
PROTECT
REFLECT
M703
M701
E
E
E
M702
C174
C173
X171
R177
BD BOARD (SIDE B)
17
Ref. No. Location
D181 D-3
D183 D-3
IC101 A-3
IC102 B-3
IC141 C-1
IC151 C-2
IC153 C-3
IC181 D-3
IC190 D-1
IC195 D-2
Q121 B-3
Q122 B-3
Q181 D-3
Q182 D-3
