HCD-M700
3-7. CONTROL Board
3-8. POWER Board
2 flexible flat cable
(CN607)
1 flexible flat cable
(CN608)
4 CONTROL board
3 two screws (+BVTP 3 × 8 )
5
6 POWER board
1 connector
(CN903)
2 co nnector (power coard)
(CN901)
4 screw (+BVTP 3 × 8
)
3 four screws (+BVTP 4 × 6 )
