• The equipment can be removed using the following procedure.
SECTION 3
DISASSEMBLY
OP-SUB ASSY
SET (HCD-M700E)
CASE (R), CASE (L),
TOP COVER SECTION
FRONT PANEL SECTION,
BACK PANEL SECTION
VIDEO BOARD,
OPTICAL BOARD
CONTROL BOARD
MAIN BOARD
POWER BOARD
DVD BOARD
DVD MECHANISM DECK
(CDM55-DVBU8)
DIGITAL BOARD
MD MECHANISM
(MDM-7B4M)
HOLDER ASSY
LOADING BOARD,
MOTOR (LD ASSY)(M901)
RF-240 BOARD
TRAY
OVER LIGHT HEAD
LOADING MOTOR ASSY (M103),
SPINDLE MOTOR ASSY (M101),
SLED MOTOR ASSY (M102)
BD BOARD
SWITCH BOARD,
JACK BOARD
TC BOARD,
MECHANISM DECK
(CMAL1Z228)
OPTICAL PICK UP
(KHM-240AAA(TYPE A))
(KHM-270AAA(TYPE B))
