26
HCD-M700
3-19. RF-240 Board
3-20. Tray
4
RF-240 board
2
flexible flat cable
(CN001)
1
flexible flat cable
(CN002)
3
three
screws (+BTP 2.6
×
6)
C
A
B
2
tray
1
While pressing the two protrusions
A
and
B
to unlock the two claws as shown,
pull the tray in the direction of the arrow
C
. (Be careful of the claws.)
claw
claw
