Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
116
HCD-M700
A-4729-887-A CONTROL BOARD, COMPLETE (AEP,UK)
********************************
A-4729-898-A CONTROL BOARD, COMPLETE (HK)
*****************************
< CAPACITOR >
C314 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C401 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C402 1-164-160-11 CERAMIC CHIP 20PF 5.00% 50V
C403 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C404 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C430 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C601 1-124-584-00 ELECT 100uF 20% 10V
C602 1-109-982-11 CERAMIC CHIP 1uF 10.00% 10V
C603 1-124-584-00 ELECT 100uF 20% 10V
C604 1-124-584-00 ELECT 100uF 20% 10V
C605 1-124-584-00 ELECT 100uF 20% 10V
C608 1-124-584-00 ELECT 100uF 20% 10V
C609 1-124-584-00 ELECT 100uF 20% 10V
C610 1-124-584-00 ELECT 100uF 20% 10V
C611 1-124-584-00 ELECT 100uF 20% 10V
C612 1-124-584-00 ELECT 100uF 20% 10V
C616 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C617 1-216-864-11 METAL CHIP 0 5% 1/16W
C624 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C626 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C627 1-216-864-11 METAL CHIP 0 5% 1/16W
C628 1-119-774-11 ELECT 100uF 20.00% 16V
C640 1-124-584-00 ELECT 100uF 20% 10V
C641 1-124-584-00 ELECT 100uF 20% 10V
C644 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C645 1-124-584-00 ELECT 100uF 20% 10V
C646 1-124-589-11 ELECT 47uF 20% 16V
C647 1-124-261-00 ELECT 10uF 20% 50V
C648 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C649 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C650 1-126-160-11 ELECT 1uF 20% 50V
C668 1-104-905-11 CAPACITOR 0.22F 5.5V
C669 1-104-905-11 CAPACITOR 0.22F 5.5V
C674 1-126-176-11 ELECT 220uF 20% 10V
C690 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
< CONNECTOR >
* CN602 1-506-992-11 PIN, CONNECTOR (PC BOARD) 10P
CN604 1-784-780-11 CONNECTOR, FFC 19P
CN605 1-784-786-11 CONNECTOR, FFC 25P
CN606 1-784-786-11 CONNECTOR, FFC 25P
CN607 1-784-369-21 CONNECTOR, FFC/FPC 10P
CN608 1-784-749-11 CONNECTOR, FFC 27P
< DIODE >
D333 8-719-991-33 DIODE 1SS133T-77
D334 8-719-991-33 DIODE 1SS133T-77
D601 8-719-991-33 DIODE 1SS133T-77
D602 8-719-991-33 DIODE 1SS133T-77
D604 8-719-991-33 DIODE 1SS133T-77
D614 8-719-200-82 DIODE 11ES2-TA1B
D615 8-719-991-33 DIODE 1SS133T-77
D616 8-719-991-33 DIODE 1SS133T-77
D620 8-719-991-33 DIODE 1SS133T-77
D622 8-719-991-33 DIODE 1SS133T-77
D623 8-719-991-33 DIODE 1SS133T-77
D625 8-719-988-61 DIODE 1SS355TE-17
D626 1-216-295-91 SHORT CHIP 0
< FERRITE BEAD >
FB314 1-216-864-11 METAL CHIP 0 5% 1/16W
FB601 1-469-144-21 FERRITE 0uH (AEP,UK)
FB601 1-216-864-11 METAL CHIP 0 5% 1/16W
(HK)
FB604 1-216-864-11 METAL CHIP 0 5% 1/16W
FB605 1-216-864-11 METAL CHIP 0 5% 1/16W
FB606 1-469-144-21 FERRITE 0uH (AEP,UK)
FB606 1-216-864-11 METAL CHIP 0 5% 1/16W
(HK)
FB607 1-469-144-21 FERRITE 0uH (AEP,UK)
FB607 1-216-864-11 METAL CHIP 0 5% 1/16W
(HK)
FB608 1-216-864-11 METAL CHIP 0 5% 1/16W
FB609 1-216-864-11 METAL CHIP 0 5% 1/16W
FB610 1-216-864-11 METAL CHIP 0 5% 1/16W
FB611 1-216-864-11 METAL CHIP 0 5% 1/16W
FB612 1-216-864-11 METAL CHIP 0 5% 1/16W
FB613 1-216-864-11 METAL CHIP 0 5% 1/16W
FB615 1-216-864-11 METAL CHIP 0 5% 1/16W
FB616 1-216-864-11 METAL CHIP 0 5% 1/16W
FB617 1-216-864-11 METAL CHIP 0 5% 1/16W
FB618 1-216-864-11 METAL CHIP 0 5% 1/16W
FB620 1-216-864-11 METAL CHIP 0 5% 1/16W
FB621 1-216-864-11 METAL CHIP 0 5% 1/16W
FB622 1-216-864-11 METAL CHIP 0 5% 1/16W
FB623 1-216-864-11 METAL CHIP 0 5% 1/16W
FB624 1-216-864-11 METAL CHIP 0 5% 1/16W
FB625 1-216-864-11 METAL CHIP 0 5% 1/16W
FB626 1-216-864-11 METAL CHIP 0 5% 1/16W
FB627 1-216-864-11 METAL CHIP 0 5% 1/16W
FB628 1-216-864-11 METAL CHIP 0 5% 1/16W
FB629 1-216-864-11 METAL CHIP 0 5% 1/16W
FB630 1-216-864-11 METAL CHIP 0 5% 1/16W
FB631 1-216-864-11 METAL CHIP 0 5% 1/16W
FB632 1-216-864-11 METAL CHIP 0 5% 1/16W
FB634 1-469-144-21 FERRITE 0uH (AEP,UK)
FB634 1-216-864-11 METAL CHIP 0 5% 1/16W
(HK)
< IC >
IC302 8-759-491-32 IC TC74VHCT04AF(EL)
IC306 6-802-159-01 IC M30622MGN-B02FP
IC602 8-759-533-04 IC M62703ML-E1
IC605 8-759-686-72 IC uPC29L04J-T
IC608 8-759-686-72 IC uPC29L04J-T
IC614 8-759-646-52 IC KIA7805API
< JUMPER RESISTOR >
JR601 1-216-864-11 METAL CHIP 0 5% 1/16W
JR602 1-216-864-11 METAL CHIP 0 5% 1/16W
