Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
123
HCD-M700
R532 1-216-833-11 METAL CHIP 10K 5% 1/16W
R533 1-216-797-11 METAL CHIP 10 5% 1/16W
R554 1-216-797-11 METAL CHIP 10 5% 1/16W
R701 1-216-833-11 METAL CHIP 10K 5% 1/16W
R711 1-218-289-11 RES-CHIP 510 5% 1/10W
R712 1-218-289-11 RES-CHIP 510 5% 1/10W
R713 1-218-289-11 RES-CHIP 510 5% 1/10W
R717 1-218-285-11 RES-CHIP 75 5% 1/10W
R718 1-218-285-11 RES-CHIP 75 5% 1/10W
R719 1-218-285-11 RES-CHIP 75 5% 1/10W
R723 1-216-833-11 METAL CHIP 10K 5% 1/16W
R724 1-216-833-11 METAL CHIP 10K 5% 1/16W
R725 1-216-833-11 METAL CHIP 10K 5% 1/16W
R731 1-216-864-11 METAL CHIP 0 5% 1/16W
R732 1-216-864-11 METAL CHIP 0 5% 1/16W
R733 1-216-864-11 METAL CHIP 0 5% 1/16W
R734 1-216-864-11 METAL CHIP 0 5% 1/16W
R735 1-216-864-11 METAL CHIP 0 5% 1/16W
R802 1-216-864-11 METAL CHIP 0 5% 1/16W
R803 1-216-864-11 METAL CHIP 0 5% 1/16W
R805 1-216-809-11 METAL CHIP 100 5% 1/16W
R806 1-216-809-11 METAL CHIP 100 5% 1/16W
R807 1-216-809-11 METAL CHIP 100 5% 1/16W
R808 1-216-809-11 METAL CHIP 100 5% 1/16W
< VARIABLE RESISTOR >
RV501 1-223-583-11 RES, ADJ, CARBON 1K
< VIBRATOR >
X101 1-795-174-11 VIBRATOR, CERAMIC 16.5MHz
X102 1-767-519-11 VIBRATOR, CRYSTAL 29MHz
*************************************************************
A-4729-890-A JACK BOARD, COMPLETE
*********************
< CAPACITOR >
C850 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C851 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C852 1-216-864-11 METAL CHIP 0 5% 1/16W
C853 1-414-170-41 INDUCTOR 100u H
C854 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< FERRITE BEAD >
FB101 1-469-144-21 FERRITE 0uH
FB201 1-469-144-21 FERRITE 0uH
FB301 1-469-144-21 FERRITE 0uH
< JACK >
J301 1-764-106-21 JACK (PHONES)
< JUMPER RESISTOR >
JR801 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L101 1-412-006-31 INDUCTOR 10uH
L201 1-412-006-31 INDUCTOR 10uH
< RESISTOR >
R849 1-216-821-11 METAL CHIP 1K 5% 1/16W
R850 1-216-815-11 METAL CHIP 330 5% 1/16W
R851 1-216-817-11 METAL CHIP 470 5% 1/16W
R852 1-216-819-11 METAL CHIP 680 5% 1/16W
R853 1-216-821-11 METAL CHIP 1K 5% 1/16W
R854 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R855 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R856 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
< SWITCH >
S825 1-571-760-11 SWITCH, KEY BOARD(PLAY MODE/DIRECTION)
S826 1-571-760-11 SWITCH, KEY BOARD (REPEAT)
S827 1-571-760-11 SWITCH, KEY BOARD (SYNCHRO MODE)
S828 1-571-760-11 SWITCH, KEY BOARD (REC MODE)
S829 1-571-760-11 SWITCH, KEY BOARD (ENTER)
S830 1-571-760-11 SWITCH, KEY BOARD (MD REC)
S831 1-571-760-11 SWITCH, KEY BOARD (TAPE PAUSE)
S832 1-571-760-11 SWITCH, KEY BOARD (TAPE REC)
*************************************************************
1-674-336-12 LOADING BOARD
**************
< CONNECTOR >
* CN151 1-568-943-11 PIN, CONNECTOR 5P
< SWITCH >
S1 1-786-203-11 SWITCH, LEVER (SLIDE)
*************************************************************
A-4729-893-A MAIN BOARD, COMPLETE (AEP,UK)
****************************
A-4729-901-A MAIN BOARD, COMPLETE (HK)
************************
4-235-238-01 BUSHING (DIA.3), INSULATING
4-237-248-01 SHEET, INSULATING
4-951-620-31 SCREW (2.6), +BVTP
7-685-546-19 SCREW +BTP 3X8 TYPE2 N-S
7-685-547-19 SCREW +BTP 3X10 TYPE2 N-S
7-685-646-79 SCREW +BVTP 3X8 TYPE2 TT(B)
< CAPACITOR >
C101 1-126-963-11 ELECT 4.7uF 20.00% 50V
C102 1-126-963-11 ELECT 4.7uF 20.00% 50V
C103 1-126-163-11 ELECT 4.7uF 20% 50V
C104 1-126-963-11 ELECT 4.7uF 20.00% 50V
C106 1-126-163-11 ELECT 4.7uF 20% 50V
C107 1-162-979-11 CERAMIC CHIP 0.0027uF 10.00% 50V
C108 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C109 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C110 1-126-963-11 ELECT 4.7uF 20.00% 50V
C111 1-115-156-11 CERAMIC CHIP 1uF 10V
C114 1-126-963-11 ELECT 4.7uF 20.00% 50V
C115 1-126-163-11 ELECT 4.7uF 20% 50V
C130 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C131 1-124-259-11 ELECT 4.7uF 20.00% 16V
C141 1-126-967-11 ELECT 47uF 20.00% 50V
