DISPLAY board
(CN606)
120 mm
MAIN board
(CN301)
80 mm
The lower side
is contact side.
The upper side
is contact side.
MAIN board
(CN109)
TOUCH PANEL board
(CN801)
45 mm
30 mm
The lower side
is contact side.
The lower side
is contact side.
MAIN board
(CN102)
DMB19 board
(CN1109)
140 mm
30 mm
The lower side
is contact side.
5 mm
MAIN board
(CN305)
DMB19 board
(CN4601)
25 mm
10 mm
The upper side
is contact side.
30 mm
12 mm
DMB19 board
(CN1107)
71 mm
DISPLAY board
(CN605)
155 mm
The lower side
is contact side.
The lower side
is contact side.
DMB19 board
(CN101)
optical pick-up
(KHM-313CAB)
22.5 mm
31.5 mm
13 mm
53 mm
60 mm
The lower side
is contact side.
The lower side
is contact side.
