HCD-SLK10D/SLK20D
6-7. FRONT PANEL SECTION
• Rear side view
301 3-087-053-01 +BVTP2.6 (3CR)
302 4-269-758-01 BUTTON (EJECT) (
Z
, – VOL +) (SLK20D)
302 4-269-758-11 BUTTON (EJECT) (
Z
, – VOL +) (SLK10D)
303 4-269-759-01 INDICATOR (SONY LOGO)
304 X-2582-894-1 PANEL (SERVICE) ASSY, FRONT
305 A-1821-486-A TOUCH PANEL BOARD, COMPLETE
306 4-269-757-01 BUTTON (POWER) (
\/1
) (SLK20D)
306 4-269-757-11 BUTTON (POWER) (
\/1
) (SLK10D)
307 1-828-324-61 WIRE (FLAT TYPE) (11 CORE) (400 mm)
308 1-828-300-61 WIRE (FLAT TYPE) (7 CORE) (160 mm)
309 1-828-293-61 WIRE (FLAT TYPE) (5 CORE) (320 mm)
LCD901 1-489-734-11 LCD MODULE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
not supplied
not supplied
(KEY_RIGHT board)
not supplied
(LOGO board)
not supplied
(KEY_LEFT board)
LCD901
302
301
303
304
305
301
301
301
301
306
307
308
309
not supplied
L
not supplied
not supplied
not supplied
not supplied
not supplied
301
L
not supplied
301
not supplied
