Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SLK10D/SLK20D
8181
< CONNECTOR >
CN401 1-794-548-21 CONNECTOR, USB (A) (
)
CN402 1-842-205-11 CONNECTOR, CARD
(MS/MSDUO/SD/M (
PRO/SD)
CN403 1-784-372-51 CONNECTOR, FFC/FPC 13P
* CN405 1-750-005-11 PIN, CONNECTOR (PC BOARD) 4P
CN406 (Not supplied) CONNECTOR, FFC/FPC (ZIF) 50P
CN408 1-784-863-51 CONNECTOR, FFC (LIF (NON-ZIF)) 11P
CN602 1-770-161-21 PIN, CONNECTOR (PC BOARD) 6P
CN604 1-784-859-51 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN605 1-784-857-51 CONNECTOR, FFC (LIF (NON-ZIF)) 5P
CN606 1-784-861-51 CONNECTOR, FFC (LIF (NON-ZIF)) 9P
< DIODE >
D401 6-500-848-01 DIODE MC2840-T112-1
D405 6-500-848-01 DIODE MC2840-T112-1
D601 6-500-619-01 DIODE RB520S-40TE61
D602 6-502-961-01 DIODE DA2J10100L
D603 8-719-053-18 DIODE 1SR154-400TE-25
D604 8-719-053-18 DIODE 1SR154-400TE-25
D605 6-500-848-01 DIODE MC2840-T112-1
D606 6-500-848-01 DIODE MC2840-T112-1
D607 6-500-848-01 DIODE MC2840-T112-1
D610 6-502-970-01 DIODE DZ2J068M0L
D611 6-503-030-01 DIODE DZ2J160M0L
D612 6-503-024-01 DIODE DZ2J110M0L
D615 6-500-619-01 DIODE RB520S-40TE61
D616 6-500-619-01 DIODE RB520S-40TE61
D617 6-500-619-01 DIODE RB520S-40TE61
D618 6-503-178-01 DIODE RB162M-40TR
D619 6-500-848-01 DIODE MC2840-T112-1
D620 6-500-848-01 DIODE MC2840-T112-1
D621 6-500-848-01 DIODE MC2840-T112-1
< EARTH TERMINAL >
ET401 1-780-482-11 EARTH TERMINAL
ET402 1-780-482-11 EARTH TERMINAL
ET403 1-780-482-11 EARTH TERMINAL
ET603 1-780-482-11 EARTH TERMINAL
< FERRITE BEAD >
FB401 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB402 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB403 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB404 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB405 1-500-283-11 INDUCTOR, FERRITE BEAD
FB406 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB408 1-500-283-11 INDUCTOR, FERRITE BEAD
FB410 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB411 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB421 1-500-283-11 INDUCTOR, FERRITE BEAD
FB601 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB602 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB603 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB604 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB605 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB606 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB607 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB608 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB609 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB610 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB611 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB614 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB615 1-500-283-11 INDUCTOR, FERRITE BEAD
FB616 1-500-283-11 INDUCTOR, FERRITE BEAD
FB617 1-500-283-11 INDUCTOR, FERRITE BEAD
FB618 1-500-283-11 INDUCTOR, FERRITE BEAD
FB619 1-500-283-11 INDUCTOR, FERRITE BEAD
FB620 1-500-283-11 INDUCTOR, FERRITE BEAD
FB621 1-500-283-11 INDUCTOR, FERRITE BEAD
FB622 1-500-283-11 INDUCTOR, FERRITE BEAD
FB623 1-500-283-11 INDUCTOR, FERRITE BEAD
FB624 1-500-283-11 INDUCTOR, FERRITE BEAD
< IC >
IC401 6-714-944-01 IC AML6226D
IC403 A-1847-217-A IC MX25L6445EM2I-10G (for SERVICE)
IC404 6-717-382-01 IC EM63A165TSB-6G
IC405 6-711-583-01 IC TS3USB221RSER
IC406 6-715-294-01 IC BD2220G-TR
IC407 6-715-164-01 IC TPS2553DBVR
IC601 6-706-106-01 IC NCP1117STAT3
IC602 6-709-217-01 IC TC74LVX4051FT
IC603 6-600-495-01 IC MM1671XNRE
IC604 6-600-495-01 IC MM1671XNRE
* IC605 6-706-293-01 IC TVP5150AM1PBSR
IC606 6-713-862-01 IC AK4388AET-E2
IC607 6-710-821-01 IC NJM2505AF (TE2)
IC609 6-715-074-01 IC MM1963DTRE
IC610 6-714-743-01 IC MM3404A18URE
< COIL >
L401 1-456-799-11 COIL, COMMON MODE CHOKE
L601 1-457-717-11 INDUCTOR 10uH
L602 1-460-353-11 INDUCTOR 22uH
L603 1-460-353-11 INDUCTOR 22uH
L604 1-469-557-21 INDUCTOR 22uH
L605 1-469-557-21 INDUCTOR 22uH
L606 1-469-557-21 INDUCTOR 22uH
L607 1-469-557-21 INDUCTOR 22uH
L609 1-469-551-21 INDUCTOR 2.2uH
L610 1-469-549-21 INDUCTOR 1uH
L611 1-469-549-21 INDUCTOR 1uH
L612 1-469-549-21 INDUCTOR 1uH
< TRANSISTOR >
Q602 6-552-514-01 TRANSISTOR 2SCR533DTL
Q603 6-550-108-01 TRANSISTOR 2SC5784 (TE85L)
Q604 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q605 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q606 8-729-620-07 TRANSISTOR 2SC3052EF-T1-LEF
Q607 6-551-696-01 TRANSISTOR ISA1235AC1-T112-1EF
< RESISTOR/CAPACITOR >
R401 1-216-809-11 METAL CHIP 100 5% 1/10W
R402 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R403 1-216-864-11 SHORT CHIP 0
R407 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R408 1-211-977-11 METAL CHIP 22 0.5% 1/10W
R409 1-216-821-11 METAL CHIP 1K 5% 1/10W
R411 1-248-311-11 RES-CHIP 0.1 1% 1/4W
DISPLAY
Note: CN406 on the DISPLAY board cannot exchange with single.
When this part is damaged, exchange the complete mounted board.
