Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-SLK10D/SLK20D
9393
RB182 1-234-372-11 RES, NETWORK 100 (1005X4)
RB187 1-234-372-11 RES, NETWORK 100 (1005X4)
< VIBRATOR >
X110 1-814-273-11 QUARTZ CRYSTAL UNIT (32.768kHz)
X114 1-795-121-21 VIBRATOR, CERAMIC (5MHz)
X385 1-814-130-11 QUARTZ CRYSTAL UNIT (24.576MHz)
************************************************************
MS-214 BOARD
************
When the MS-214 board is defective, exchange the CDM86 (S) ASSY.
************************************************************
TERMINAL BOARD
***************
< CAPACITOR >
C690 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C691 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
CN611 1-564-505-11 PLUG, CONNECTOR 2P (SLK10D)
CN612 1-564-506-11 PLUG, CONNECTOR 3P (SLK10D)
CN613 1-564-507-11 PLUG, CONNECTOR 4P (SLK20D)
CN614 1-564-507-21 PLUG, CONNECTOR 4P (SLK20D)
< COIL >
L659 1-457-077-11 AIR-CORE COIL
L660 1-457-078-11 AIR-CORE COIL
L661 1-457-077-11 AIR-CORE COIL
L662 1-457-078-11 AIR-CORE COIL
< TERMINAL >
TB601 1-780-859-11 TERMINAL BOARD (SPEAKER) (SPEAKERS)
************************************************************
A-1821-486-A TOUCH PANEL BOARD, COMPLETE
****************************
When the TOUCH PANEL board is defective, exchange the complete mouted
board.
************************************************************
MISCELLANEOUS
**************
103 1-500-386-11 FILTER, CLAMP (FERRITE CORE) (SLK20D)
103 1-543-798-11 FILTER, CLAMP (FERRITE CORE) (SLK10D)
105 1-828-301-61 WIRE (FLAT TYPE) (7 CORE) (200 mm)
154 1-828-304-61 WIRE (FLAT TYPE) (7 CORE) (400 mm)
155 1-838-111-21 CABLE, FLEXIBLE FLAT (5 CORE) (620 mm)
201 1-500-386-11 FILTER, CLAMP (FERRITE CORE) (TH)
201 1-543-798-11 FILTER, CLAMP (FERRITE CORE) (EXCEPT TH)
0
202 1-834-288-12 CORD, POWER (TH)
0
202 1-834-966-21 CORD, POWER (E2, E51, SP)
0
202 1-835-706-11 CORD, POWER-SUPPLY (BR)
0
202 1-837-309-41 CORD, POWER-SUPPLY (EA)
0
202 1-837-343-11 CORD, POWER-SUPPLY (MX)
0
202 1-837-822-11 CORD, POWER-SUPPLY (CH)
0
202 1-839-012-21 CORD, POWER-SUPPLY (IND)
0
203 1-569-008-33 ADAPTOR, CONVERSION (E2, E51, SP)
253 1-828-310-61 WIRE (FLAT TYPE) (9 CORE) (160 mm)
254 1-827-731-61 WIRE (FLAT TYPE) (11 CORE) (200 mm)
255 1-828-333-61 WIRE (FLAT TYPE) (13 CORE) (320 mm)
256 1-838-111-21 CABLE, FLEXIBLE FLAT (5 CORE) (620 mm)
257 1-828-312-61 WIRE (FLAT TYPE) (9 CORE) (250 mm)
258 1-828-320-61 WIRE (FLAT TYPE) (11 CORE) (160 mm)
307 1-828-324-61 WIRE (FLAT TYPE) (11 CORE) (400 mm)
308 1-828-300-61 WIRE (FLAT TYPE) (7 CORE) (160 mm)
309 1-828-293-61 WIRE (FLAT TYPE) (5 CORE) (320 mm)
351 1-838-443-11 FLEXIBLE FLAT CABLE 24P (250 mm)
401 A-1800-839-A CDM86 (S) ASSY (Including MS-214 board)
0
405 8-820-322-04 OPTICAL PICK-UP BLOCK (KHM-313CAB/C2RP)
(Including sled motor, spindle motor)
LCD901 1-489-734-11 LCD MODULE
0
M601 1-787-344-11 FAN, DC
0
SWR1 1-474-215-11 REGULATOR, SWITCHING
TU1 1-693-737-21 TUNER (FM/AM)
MS-214MAIN TOUCH PANELTERMINAL
To Next Page
