To output as SD-SDI
To output as VBS
Outputting the same image as that on the
viewfinder screen
• With HD-SDI, you can obtain a signal that includes the
same information as that being displayed on the
viewfinder screen according to the settings of the VF
MARKER, CHARACTER, VF DETAIL, ZEBRA, etc. The ON/
OFF or other settings for adding information are common
to those for the viewfinder. The output is synchronized
with switching among Y, R, G, and B or switching to a
return signal.
• With SD-SDI or VBS, the output is synchronized only with
switching between a return signal and the camera image.
It does not correspond to switching among Y, R, G, and B.
Information other than CHARACTER (such as VF MARKER,
VF DETAIL, ZEBRA) cannot be added to the output.
Note
With the settings for outputting the same image as that on
the viewfinder screen, the output will be obtained in 1080i,
even if the format setting is 720P.
To output as HD-SDI
To output as SD-SDI
To output as VBS
Outputting 3G/6G/12G-SDI (HDC5500)
The SDI 1 output and SDI 2 output form 3G/6G/12G-SDI
output.
For details, see “SDI output format with master frequency
of 1/1.001” (page 64) and “SDI output format with master
frequency of 1/1.000” (page 77).
Outputting 3G-SDI (HDC3500)
The SDI 1 output and SDI 2 output form 3G-SDI output.
To output in 1080/59.94P or 1080/50P
Notes
• HZC-PRV50/PRV50M/PRV50W camera operating
software (option) is required for 3G-SDI output.
• Output as standard when an HKC-TR37 is installed.
Menu page Item Setting
<SDI OUT> SDI-MONI OUT SD-SDI
DOWN CONVERTER
SELECT
RET
Menu page Item Setting
<TEST OUT> OUTPUT VBS
DOWN CONVERTER
SELECT
RET
Menu page Item Setting
<SDI OUT> SDI-MONI OUT VF
Menu page Item Setting
<SDI OUT> SDI-MONI OUT SD-SDI
DOWN CONVERTER
SELECT
VF
Menu page Item Setting
<TEST OUT> OUTPUT VBS
DOWN CONVERTER
SELECT
VF
Menu page Item Setting
<OUTPUT FORMAT> ACTIVE LINE 1080
(Format) 59.94P or 50P
<SDI OUT> SDI-1
SDI-2
MAIN (3G)
LEVEL-A or LEVEL-B
To Next Page
