64
SDI output format with master frequency of 1/1.001
The following table shows the SDI output formats when the master frequency is 1/1.001.
The SDI output format will vary depending on the combination of camera model, transmission adaptor, and camera
operating software.
1. Using HDC5500 or HDC3500 with HKC-CN50 and HKC-FB50 installed
<Standard format>
*1
Can be selected only when NETWORK TRUNK > DATA RATE (setting on the CCU) is set to 100Mbps.
*2
Can be selected only when a CCU is connected.
*3
Can be selected only in standalone operation.
<OTHERS>
M19
FAN MODE OFF, AUTO1
, AUTO2, MIN, MAX AUTO1: Normal rotation
AUTO2: Slow rotation
CAM BARS ON, OFF
, (OFF) (OFF): Displayed only for 4K/HDR format.
WHITE SETUP MODE AWB, A.LVL
STANDALONE PAINT
SWITCH
OFF, ON When set to ON, disables operation of the unit’s
switches, such as the WHITE BAL switch, even when
a CCU or control panel is not connected.
HD DOWNCONV FILTER 1
, 2, 3, 4, 1(V0.3), 1(V0.6), (4) (4): Displayed only for 4K/HDR format.
<OPTION KEY>
M20
READ (USB t CAM) Execute using ENTER. Reads the install key from a USB drive.
EFFECTIVE FUNCTION Displayed only when option function is installed.
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 59.94P S-Log3
HLG
OFF
HD/3G-A/HDR
HD/3G-A/SDR
HD/3G-B/HDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
OFF
HD/3G-A/HDR
HD/3G-A/SDR
HD/3G-B/HDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
–
–
–
–
SDR OFF
HD/3G-A/SDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD PROMPTER
–
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
OFF
HD/3G-A/SDR
HD/3G-B/SDR
HD/1.5G/SDR
UHD TRUNK(12G) IN
*1 *2
UHD TRUNK(6G) IN
*1 *2
UHD TRUNK(3G) IN
*1 *2
HD/UHD TRUNK(1.5G) IN
*2
HD RETURN IN
*3
–
1920×1080/59.94P
1920×1080/59.94P
1920×1080/59.94i
–
–
–
–
–
MAINTENANCE
Page name
Page No.
Item Settings Description
