<TEST OUT>
M12 (U13)
OUTPUT Display only Displays the current format.
VBS-OUT Displayed when OUTPUT is set to VBS.
CHARACTER ON, OFF
GAIN –99 to +99, 0
CHROMA –99 to +99, 0
SETUP OFF, ON
DOWN CONVERTER Displayed when OUTPUT is set to VBS.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC Displayed when OUTPUT is set to VBS (NTSC).
SYNC-OUT Displayed when OUTPUT is set to SD-SYNC or
HD-SYNC.
V-PHASE –999 to +999, 0
H-PHASE –999 to +999, 0
<SDI OUT>
M13 (U14)
SDI-1 See “SDI output format with
master frequency of 1/1.001”
(page 64).
Sets the SDI-1 and SDI-2 output formats.
SDI-2
SDI-MONI OUT MAIN, VF
, RET, SD-SDI, OFF
CHARACTER ON, OFF
Displayed when SDI-MONI OUT is not set to VF.
EMB AUDIO OFF
, MIC, PGM
DOWN CONVERTER Displayed when SDI-MONI OUT is set to SD-SDI.
SELECT MAIN
, RET, VF
ASPECT SQ
, EC
<TRUNK>
M14
TRUNK ON
, OFF
INTERFACE 232c
, 422A
AUX REMOTE Display only
NETWORK TRUNK Display only
LINK
<GENLOCK>
M15
REFERENCE Synchronization status Display only
GENLOCK ENABLE
, DISABLE Not displayed when a CCU is connected.
STATUS
FORMAT
PHASE
V –1024 to 1023, 0
H –1700 to 1700, 0
<DATE>
M16
DATE/TIME 2000 to 2035/01 to 12/00 to 31
00 to 23: 00 to 59
DATE FORMAT 1 Y/Mn/D, 2 Mn/D, 3 D/M/Y
4 D/M, 5 M/D/Y
, 6 M/D
Y: Year
Mn: Month (numeric)
M: Month (English abbreviation)
D: Day
<BATTERY ALARM>
M17
BEFORE END 11.5
to 17.0 V
END 11.0
to 11.5 V
<SIMPLE PROTOCOL>
M18
TRANSPORT CONVERTER
MODE
DISABLE
, ENABLE Enables transport conversion mode to enable
camera control using transmission lines/networks
with high latency, such as wireless transmission.
PORT REMOTE(RS-422A)
,
CRANE(RS-422A),
CRANE(RS-232C), WIRELESS SIDE
PANEL(RS-422A), WIRELESS SIDE
PANEL(RS-232C)
Sets the port to enable for transport conversion
mode.
WIRELESS SIDE PANEL(RS-422A) or WIRELESS SIDE
PANEL(RS-232C) can be selected only when an
HKC-WL50 Wireless Transmission Adaptor is
installed.
BAUDRATE 9.6kbps to 843.75kbps,
115.2kbps
Communication speed
