<ZEBRA>
09 (U08)
ZEBRA ON, OFF
1, 2, 1&2
ZEBRA1
LEVEL 50 to 109%, 70%
WIDTH 0 to 30%, 10%
ZEBRA2 50 to 109%, 100%
<CURSOR>
10 (U07)
CURSOR ON, OFF Displayed only if HDLA attached.
LEVEL WHITE
, BLACK, DOT
MIN, 1 to 10, 4
BOX/CROSS BOX, CROSS
H POSITION 0 to 99, 50
Displayed only if HDLA attached.
V POSITION 0 to 99, 50
WIDTH 0 to 99, 50
HEIGHT 0 to 99, 50
BOX MEMORY 1/2/3: OFF, ON
H POSI 1/2/3: 0 to 99, 50
V POSI 1/2/3: 0 to 99, 50
WIDTH 1/2/3: 0 to 99, 50
HEIGHT 1/2/3: 0 to 99, 50
<VF DYNAMIC
CONTRAST>
11
DYNAMIC CONTRAST ON, OFF, (OFF) (OFF) is displayed when CAM BARS is set to ON.
GAIN 0 to 100%, 30%
FILTER NARROW, MIDDLE, WIDE
MODE LINEAR, HIGHLIGHT
, FOGGY
<BOX CURSOR FILE>
12
1: BOX CURSOR FILE selection FILE name input.
Align the cursor to the left of the number to select
the BOX CURSOR FILE.
Align the cursor to the right of the number to enter
the BOX CURSOR FILE name.
See
“To specify a character string” (page 30)
.
2:
3:
4:
5:
STORE Stores a BOX CURSOR FILE name in the camera.
READ (USB t CAM) Transfers a BOX CURSOR FILE from a USB drive to
the camera.
WRITE (CAM t USB) Transfers a BOX CURSOR FILE from the camera to a
USB drive.
<SPIRIT LEVEL>
13
INDICATOR ON, OFF
MODE 1, 2 Switches the display method of the indicator.
REVERSE OFF
, ON Inverts the movement of the indicator horizontally.
SCALE 50% to 150%, 100%
Adjusts the horizontal width of the indicator.
H POSITION 0 to 99, 50
V POSITION 0 to 99, 97
ANGLE Displays the inclination angle (display only).
OFFSET –90 to +90, 0
SET ZERO ANGLE Execute using ENTER. Designates the current angle as level (0°).
CLEAR Execute using ENTER. Sets OFFSET to 0.
