58
<SHUTTER>
P16
SHUTTER ON, OFF
, (ON), (OFF) Settings in ( ): When a remote control unit/panel or a
CCU is not connected (cannot be changed)
59.94i: 1/100
, 1/125, 1/250,
1/500, 1/1000, 1/2000
50i: 1/60, 1/125
, 1/250, 1/500,
1/1000, 1/2000
29.97PsF: 1/40, 1/60, 1/100,
1/120, 1/125, 1/250, 1/500,
1/1000, 1/2000
25PsF: 1/33, 1/50, 1/100,
1/125, 1/250, 1/500, 1/1000,
1/2000
24PsF/23.98PsF: 1/32, 1/48,
1/96, 1/100, 1/125, 1/250,
1/500, 1/1000, 1/2000
59.94P: 1/100, 1/125, 1/250,
1/500, 1/1000, 1/2000
50P: 1/60, 1/125, 1/250,
1/500, 1/1000, 1/2000
Step shutter selection
ECS FREQ 59.94i: 59.96
to 4300 Hz
50i: 50.00 to 4700 Hz
29.97PsF: 29.97 to 2700 Hz
25PsF: 25.00 to 2300 Hz
24PsF/23.98PsF: 24.00 to
2200 Hz
59.94P: 59.96 to 4600 Hz
50P: 50.03 to 4600 Hz
<NOISE
SUPPRESSION>
P17
SUPPRESSION 0
to 100%
ON, OFF
<FLICKER
REDUCTION>
P18
REDUCTION ON, OFF, (OFF) (OFF): Displayed for normal speed formats other
than HFR.
Note
When you turn REDUCTION ON or OFF, noise may be
generated. This is not a malfunction.
POWER LINE FREQUENCY 50 Hz
, 60 Hz Specifies the frequency of the lighting power
source.
MODE STANDARD
, ACM, (OFF) STANDARD: Corrects flicker without adding an
image.
ACM: Corrects flicker by adding images.
(OFF): Displayed for normal speed formats other
than HFR.
GAIN –99 to +99, 0
Enabled only when STANDARD is selected.
Sets the correction gain.
OFFSET 0
to 99 Enabled only when STANDARD is selected.
Sets the brightness level that invokes correction.
ACM TYPE 1
, 2, 3, 4 Enabled only when ACM is selected.
Selects the combination of frames to add. More
frames are added as the value increases.
PAINT
Page name
Page No.
Item Settings Description
