3. Using HDC3500 with HKC-CN50 and HKC-TR37 installed for digital triax transmission (equivalent to
HDC3170)
<Standard format>
*1
Can be selected only when a CCU is connected.
*2
Can be selected only in standalone operation.
<When HZC-PSF50/PSF50M/PSF50W is installed>
4. Using HDC3500 with HKC-CN50 and HKC-WL50 installed
<Standard format>
<When HZC-PSF50/PSF50M/PSF50W is installed>
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1
RESOLUTION FREQUENCY OETF Settings Output formats
1920×1080 50P S-Log3
HLG
*2
OFF
HD/3G-A/HDR
HD/3G-B/HDR
–
1920×1080/50P
1920×1080/50P
SDR OFF
HD/3G-A/SDR
HD/3G-B/SDR
–
1920×1080/50P
1920×1080/50P
50P(4K/HDR)
*1
Set by
CCU
OFF –
50I
*1
SDR
(fixed)
OFF
HD/1.5G/SDR
–
1920×1080/50i
1280×720 50P SDR
(fixed)
OFF
HD/1.5G/SDR
–
1280×720/50P
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1
RESOLUTION FREQUENCY OETF Settings Output formats
1920×1080 25PsF SDR
(fixed)
OFF
HD/1.5G/SDR
–
1920×1080/25PsF
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 50i SDR
(fixed)
HD/1.5G/SDR 1920×1080/50i OFF
HD RETURN IN
–
–
1280×720 50P SDR
(fixed)
HD/1.5G/SDR 1280×720/50P OFF
HD RETURN IN
–
–
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 25PsF SDR
(fixed)
HD/1.5G/SDR 1920×1080/25PsF OFF
HD RETURN IN
–
–
24PsF SDR
(fixed)
HD/1.5G/SDR 1920×1080/24PsF OFF
HD RETURN IN
–
–
