<When HZC-PRV50/PRV50M/PRV50W is installed>
<When HZC-HFR50/HFR50M/HFR50W/HFR50P is installed>
<When HZC-DFR50/DFR50M/DFR50W is installed>
<When HZC-UHD50/UHD50M/UHD50W/UHD50P is installed>
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 50P S-Log3
HLG
HD/3G-B/HDR 1920×1080/50P OFF
HD RETURN IN
HD/3G-B/SDR
–
–
1920×1080/50P
SDR HD/3G-B/SDR 1920×1080/50P OFF
HD RETURN IN
–
–
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 50P S-Log3
HLG
HD/3G-B/HDR 1920×1080/50P OFF
HD RETURN IN
–
–
SDR HD/3G-B/SDR 1920×1080/50P OFF
HD RETURN IN
–
–
50P(2×) S-Log3
HLG
HD/3G-A/HDR/HFR 1920×1080/50P/Link A-B OFF
HD RETURN IN
–
–
SDR
HD/3G-A/SDR/HFR 1920×1080/50P/Link A-B OFF
HD RETURN IN
–
–
50P(3×) S-Log3
HLG
HD/3G-A/HDR/HFR 1920×1080/50P/Link A-C OFF
HD RETURN IN
–
–
SDR
HD/3G-A/SDR/HFR 1920×1080/50P/Link A-C OFF
HD RETURN IN
–
–
50P(4×) S-Log3
HLG
HD/3G-A/HDR/HFR 1920×1080/50P/Link A-D OFF
HD RETURN IN
–
–
SDR
HD/3G-A/SDR/HFR 1920×1080/50P/Link A-D OFF
HD RETURN IN
–
–
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
1920×1080 50P(2x) S-Log3
HLG
HD/3G-A/HDR/HFR 1920×1080/50P/Link A-B OFF
HD RETURN IN
–
–
SDR
HD/3G-A/SDR/HFR 1920×1080/50P/Link A-B OFF
HD RETURN IN
–
–
SYSTEM FORMAT HDR/
SDR
OUTPUT FORMAT
SDI-1 SDI-2
RESOLUTION FREQUENCY OETF Settings Output formats Settings Output formats
3840×2160 50P S-Log3
HLG
4K/12G/HDR
4K/3G-A/HDR
3840×2160/50P
3840×2160/50P
OFF
HD RETURN IN
HD/3G-B/SDR
–
–
1920×1080/50P
SDR 4K/12G/SDR
4K/3G-A/SDR
3840×2160/50P
3840×2160/50P
OFF
HD RETURN IN
HD/3G-B/SDR
–
–
1920×1080/50P
