V09: WHITE CLIP
Menu screen Item Setting
<WHITE CLIP> → V09 TOP
[R] [G] [B] [M]
W-CLIP : 0 0 0 0
: ON
W-CLIP R/G/B/M ±99
ON/OFF
V10: USER MATRIX
Menu screen Item Setting
<USER MATRIX> → V10 TOP
[-R] [-G] [-B]
R : -- 0 0
G : 0 -- 0
B : 0 0 --
MATRIX : OFF
PRESET : ---
USER MATRIX : ---
ADAPTIVE MATRIX : ---
MATRIX R-G/R-B ±99
MATRIX G-R/G-B ±99
MATRIX B-R/B-G ±99
MATRIX ON/OFF
PRESET ON/OFF
USER MATRIX ON/OFF
ADAPTIVE MATRIX ON/OFF
V11: MULTI MATRIX
Menu screen Item Setting Description
<MULTI MATRIX> → V11 TOP
PHASE : 0
HUE : 0
SAT : 0
ALL CLEAR
MATRIX : OFF
PRESET : ---
MULTI MATRIX: ---
PHASE 0, 23, 45, 68, 90,
113, 135, 158, 180,
203, 225, 248, 270,
293, 315, 338
Selects an angle (from 16 an-
gles) that varies the multi-ma-
trix correction function.
HUE ±99 Adjusts the multi-matrix correc-
tion value of hue for each
PHASE (16 angles).
SAT ±99 Adjusts the multi-matrix correc-
tion value of saturation for each
PHASE (16 angles).
ALL CLEAR Clears HUE and SAT of all 16
angles to 0.
MATRIX ON/OFF
PRESET ON/OFF
MULTI MATRIX ON/OFF
V12: DETAIL 1
Menu screen Item Setting
<DETAIL 1> → V12 TOP
DETAIL : ON
LEVEL : 0
LIMITER [M] : 0
[WHT]: 0
[BLK]: 0
CRISP : 0
LVL DEP : 0 : ON
DETAIL ON/OFF
LEVEL ±99
LIMITER [M] ±99
[WHT] ±99
[BLK] ±99
CRISP ±99
LEVEL DEP ±99
ON/OFF
HXCU-FB80
6-6
