Sony HXCU-FB80 Service Manual

6-3. MAINTENANCE Menu
M01: SERIAL NO SET
Menu screen Item Setting Description
<SERIAL NO SET> → M01 TOP
SERIAL NO:00000000
NAME: HXCU-FB80
DEST: SYL
WRITE
EDIT CANCEL
TIMER-RESET
FACTORY-RECALL
SERIAL NO 00000000 to
99999999
The setup information is stored in the
EEPROM (IC309) on the DPR-386
board.
NAME HXCU-FB80
DEST SYL Com-
mon
J Japan
UC United
States
CE Europe
WRITE Writes the above setup information
to the EEPROM. Place the cursor at
“WRITE” and turn the CANCEL/
ENTER lever to the ENTER side. A
message “SERIAL NO WRITE
OK?” appears.
Turn the CANCEL/ENTER lever to
the ENTER side again to perform the
processing.
EDIT CANCEL Restores the setup information dur-
ing editing to the previous informa-
tion before editing.
Place the cursor at “EDIT-CAN-
CEL” and turn the CANCEL/
ENTER lever to the ENTER side.
A message “EDIT DATA CANCEL
OK?” appears.
Turn the CANCEL/ENTER lever to
the ENTER side again to perform the
processing.
TIME-RESET Resets the timer for displaying pow-
er-on hours.
FACTORY-RE-
CALL
Resets all the setting values except
the following items to the factory
settings.
• Media access control (MAC)
address
• Serial number
• Power-on hours display timer
• Setting values stored in the
EEPROM on the DPR-386
board through the PLD.
Processing result indication
Setting Item Normal end Abnormal end Description
WRITE SERIAL NO
WRITE OK
MODEL NAME IS
WRONG
The NAME (model name) set-
ting is not correct.
DEST NAME IS
WRONG
The DEST (destination) setting
is not correct.
SERIAL NO
WRITE NG
Data cannot be written to the
EEPROM.
EDIT-CANCEL EDIT DATA CAN-
CEL OK
—
HXCU-FB80
6-13
