Sony HXCU-FB80 Service Manual

V30: OTHERS
Menu screen Item Setting
<OTHERS> → V30 TOP
V DTL CREATION : Y
DTL H/V MODE : H/V
WHITE SETUP MODE: A.LVL
WHITE GAMMA RGB : OFF
V DTL CREATION NAM/G/R+G/Y
DTL H/V MODE H/V, V ONLY
WHITE SETUP MODE A.LVL/RGB
WHITE GAMMA RGB ON/OFF
V31: AUTO SETUP
Menu screen Item Setting Description
<AUTO SETUP> → V31 TOP
Auto Message
AUTO BLACK
AUTO WHITE
AUTO LEVEL
AUTO WHITE SHADING
AUTO BLACK SHADING
TEST : OFF
AUTO BLACK To execute:
Place the cursor at the item to be
adjusted.
Turn the CANCEL/ENTER lev-
er to the ENTER side.
AUTO WHITE
AUTO LEVEL
AUTO WHITE
SHADING
AUTO BLACK
SHADING
To cancel:
Turn the CANCEL/ENTER lev-
er to the ENTER side during ex-
ecution.
TEST OFF/1/2
The following messages are displayed in the shaded Auto Message.
Adjustment
item
Prepara-
tion for ex-
ecution
During execution Normal end Abnormal end Cancel
AUTO BLACK — ABB: EXECUTING ABB: OK ABB: NG ABB: BREAK
AUTO WHITE — AWB: EXECUTING AWB: OK AWB: NG AWB: BREAK
AUTO LEVEL — LEVEL AUTO: EXE-
CUTING
LEVEL AUTO:
OK
LEVEL AUTO:
NG
LEVEL AUTO:
BREAK
AUTO WHITE
SHADING
— AWS: EXECUTING AWS: OK AWS: NG AWS: BREAK
AUTO BLACK
SHADING
— ABS: EXECUTING ABS: OK ABS: NG ABS: BREAK
V32: CCU VIDEO
Menu screen Item Setting Description
<CCU VIDEO> → V32 TOP
VBS CHROMA : ON
MONO COLOR : OFF
PHASE : 0
SATURATION: 0
VBS CHROMA ON/OFF
MONO COLOR ON/OFF
PHASE 0, 359 to 270 to 180
to 90
The setting value decreases
when the rotary encoder is rota-
ted clockwise.
SATURATION ±99
HXCU-FB80
6-12
