V27: WHITE SHADING
Menu screen Item Setting Description
<WHITE SHADING> → V27 TOP
[R] [G] [B]
V SAW : 0 0 0
V PARA : 0 0 0
H SAW : 0 0 0
H PARA : 0 0 0
WHITE : 0 0 0
AUTO WHITE SHADING
WHITE SHAD MODE: RGB
V SAW R/G/B ±99
V PARA R/G/B ±99
H SAW R/G/B ±99
H PARA R/G/B ±99
WHITE R/G/B ±99
AUTO WHITE
SHADING
To execute:
Place the cursor at “AUTO
WHITE SHADING” and turn
the CANCEL/ENTER lever to
the ENTER side.
To cancel:
Turn the CANCEL/ENTER lev-
er to the ENTER side during ex-
ecution.
WHITE SHAD
MODE
RB/RGB
V28: AUTO IRIS
Menu screen Item Setting
<AUTO IRIS> → V28 TOP
WINDOW : 1
IRIS LEVEL: 0
APL RATIO : 65
IRIS GAIN : 0
AUTO IRIS : OFF
WINDOW 1 to 6
IRIS LEVEL ±99
APL RATIO ±99
IRIS GAIN ±99
AUTO IRIS ON/OFF
V29: OHB MATRIX
Menu screen Item Setting Description
<OHB MATRIX> → V29 TOP
[-R] [-G] [-B]
R : -- 0 0
G : 0 -- 0
B : 0 0 --
PHASE : 0
HUE : 0
SAT : 0
OHB MATRIX: OFF
R-G/R-B ±99
G-R/G-B ±99
B-R/B-G ±99
PHASE 0, 23, 45, 68, 90,
113, 135, 158, 180,
203, 225, 248, 270,
293, 315, 338
Selects an angle (from 16 an-
gles) that varies the OHB matrix
correction function.
HUE ±99 Adjust the OHB multi-matrix
correction value of hue for each
PHASE (16 angles).
SAT ±99 Adjusts the OHB multi-matrix
correction value of saturation
for each PHASE (16 angles).
OHB MATRIX ON/OFF
HXCU-FB80
6-11
