Sony HXCU-FB80 Service Manual

V24: SD USER MATRIX
Menu screen Item Setting
<SD USER MATRIX>→ V24 TOP
[-R] [-G] [-B]
[R] : --- : 0 : 0
[G] : 0 : --- : 0
[B] : 0 : 0 : ---
MATRIX : OFF
PRESET MATRIX: ON
USER MATRIX : OFF
R-G/R-B ±99
G-R/G-B ±99
B-R/B-G ±99
MATRIX ON/OFF
PRESET MATRIX ON/OFF
USER MATRIX ON/OFF
V25: SD MULTI MATRIX
Menu screen Item Setting Description
<SD MULT MATRIX>→ V25 TOP
PHASE : 0( 0)
HUE : 0
SATURATION : 0
ALL PRESET
MATRIX : OFF
PRESET MATRIX: ON
MULTI MATRIX : OFF
PHASE 0, 23, 45, 68, 90,
113, 135, 158, 180,
203, 225, 248, 270,
293, 315, 338
Selects an angle (from 16 an-
gles) that varies the SD multi-
matrix correction function.
HUE ±99 Adjusts the SD multi-matrix
correction value of hue for each
PHASE (16 angles).
SATURATION ±99 Adjusts the SD multi-matrix
correction value of saturation
for each PHASE (16 angles).
ALL PRESET
MATRIX ON/OFF
PRESET MATRIX ON/OFF
MULTI MATRIX ON/OFF
V26: BLACK SHADING
Menu screen Item Setting Description
<BLACK SHADING> → V26 TOP
[R] [G] [B] [M]
V SAW : 0 0 0
V PARA : 0 0 0
H SAW : 0 0 0
H PARA : 0 0 0
BLK SET: 0 0 0
BLACK : 0 0 0 0
MASTER GAIN: 0dB
AUTO BLACK SHADING
GAIN BOUNCE: OFF
V SAW R/G/B ±99
V PARA R/G/B ±99
H SAW R/G/B ±99
H PARA R/G/B ±99
BLK SET R/G/B ±99
BLACK R/G/B/M ±99
MASTER GAIN –3dB to +12dB
AUTO BLACK
SHADING
To execute:
Place the cursor at “AUTO
BLACK SHADING”, and turn
the CANCEL/ENTER lever to
the ENTER side.
To cancel:
Turn the CANCEL/ENTER lev-
er to the ENTER side during ex-
ecution.
GAIN BOUNCE ON/OFF
HXCU-FB80
6-10
