Installation dimensions table
Screen centre point/
125
Length for each mounting angle/
AB C DEFGH
KLV-26S400A
675
466 83
335 157
269 453 342
KLV-26T400A / KLV-26T400G
KLV19T400A / KLV-19T400G
789 448 83 318 155 266 428 324
595 348 116 300 152 237 331 308
Model Name/
Display
dimensions/
Screen centre
dimension/
Angle (0
o
)/
Angle (20
o
)/
Unit: mm
Installation dimensions may differ according to how the TV is installed.
