10
3-6. TUNER BOARD
3-7. HOLDER, CASSETTE
2 BVTP 3x10
6 TUNER board
3 BVTP 3x10
4 CNP1
5 Removal the solder.
1 screw
2 boss
3 boss
4 holder, cassette
1 spring, cassette
