– 77 –
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3322-766-A CD BOARD, COMPLETE
*******************
< CAPACITOR >
C701 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C702 1-124-589-11 ELECT 47uF 20% 16V
C703 1-124-584-00 ELECT 100uF 20% 10V
C704 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C705 1-124-584-00 ELECT 100uF 20% 10V
C706 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C707 1-124-584-00 ELECT 100uF 20% 10V
C708 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C709 1-124-234-00 ELECT 22uF 20% 16V
C710 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C711 1-124-589-11 ELECT 47uF 20% 16V
C712 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C713 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C714 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C715 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C716 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C717 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C718 1-126-176-11 ELECT 220uF 20% 10V
C719 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C720 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C721 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C722 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C723 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C724 1-124-584-00 ELECT 100uF 20% 10V
C725 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C726 1-124-584-00 ELECT 100uF 20% 10V
C727 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C728 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C729 1-124-465-00 ELECT 0.47uF 20% 50V
C730 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C731 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C732 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C733 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C734 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C736 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C737 1-163-095-00 CERAMIC CHIP 12PF 5% 50V
C738 1-163-103-00 CERAMIC CHIP 27PF 5% 50V
C739 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C740 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C742 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C743 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C744 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C745 1-163-121-00 CERAMIC CHIP 150PF 5% 50V
C746 1-163-137-00 CERAMIC CHIP 680PF 5% 50V
C747 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C749 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C750 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C751 1-163-005-11 CERAMIC CHIP 470PF 10% 50V
C752 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C753 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C754 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C755 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C756 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C757 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C758 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C760 1-126-163-11 ELECT 4.7uF 20% 50V
C761 1-126-163-11 ELECT 4.7uF 20% 50V
C762 1-124-584-00 ELECT 100uF 20% 10V
C763 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C765 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C766 1-124-261-00 ELECT 10uF 20% 50V
C767 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CNP701 1-770-168-11 CONNECTOR, FFC/FPC 16P
CNP702 1-695-376-21 PIN, CONNECTOR (PC BOARD) 15P
CNP703 1-770-540-31 PIN, CONNECTOR (PC BOARD) 6P
< DIODE >
D701 8-719-988-61 DIODE 1SS355TE-17
D702 8-719-970-02 DIODE 1SR139-400
D703 8-719-970-02 DIODE 1SR139-400
D704 8-719-970-02 DIODE 1SR139-400
D705 8-719-970-02 DIODE 1SR139-400
< FERRITE BEAD >
FB701 1-410-397-21 FERRITE BEAD INDUCTOR 1.1uH
FB702 1-410-397-21 FERRITE BEAD INDUCTOR 1.1uH
< IC >
IC701 8-752-085-50 IC CXA2568M
IC702 8-752-386-85 IC CXD2587Q
IC703 8-759-549-27 IC BA5974FP
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
CD
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
To Next Page
