Sony PMC-DR45 - Power Board

– 15 –
qa CD mechanism bloc
k
CD mechanism block
0 arm
1 PWH 2.6x10
4 PWH 2.6x10
8 PWH 2.6x10
5
7
6
9
2 gear, drive
3 gear
arm
chassis
chassis
1 scews +B tapping
2 scews +B tapping
3 cabinet (rear), speaker
4 bracket, cover
qa BVTP 3x10
qs BVTP 3x10
qd B 4x6
9 BTP 2.6x8
0 speaker board
qf power board
5 CNP903
6 CNP911
7 CNP901
8 CNP902
3-16. CD MECHANISM BLOCK
3-17. POWER BOARD
