– 22 –
Pin No. Pin Name I/O Pin Description
51 A-MUTE O System mute signal output
52 B-MUTE O Tuner mute signal output
53 C-MUTE O CD mute signal output
54 LINE-MUTE O Line out mute signal output
55 C-AGCCNT O CD AGC control signal output
56 T-REC O Tape REC signal output
57 T-BIAS O Tape bias signal output
58 T-SOL. O Tape solenoid signal output
59 T-MTR O Tape motor signal output
60 ISS1 O ISS1 signal output
61 ISS2 O ISS2 signal output
62 PWR-SAVE O Power save signal output
63 P-CON O Power control signal output
64 T-AMS.MUTE O Not used. (Open) Tape AMS mute signal output
65 LINE O Not used. (Open) Line out signal output
66 RDS-ON O RDS on signal output (Not used in this set.)
67 TAPE O Tape function signal output
68 TU O Tuner function signal output
69 CD O CD function signal output
70, 71 NC — Not used. (Open)
72 – 87 SEG16-1 O Segment signal output
88 NC — Not used. (Open)
89 VDD — Power supply pin
90 NC — Not used. (Open)
91 G12 O GRID 12 signal output
92 G11 O GRID 11 signal output
93 G10 O GRID 10 signal output
94 G9 O GRID 9 signal output
95 G8 O GRID 8 signal output
96 G7 O GRID 7 signal output
97 G6 O GRID 6 signal output
98 G5 O GRID 5 signal output
99 G4 O GRID 4 signal output
100 G3 O GRID 3 signal output
