11
RCD-W10
3-9. Holder (MG) Sub Assy, Dust Cover
3-10. Optical Pick-Up (KRM-220CAA)
4 three s crews
(+BVTP 2.6
× 8)
3 holder (MG)
sub assy
1 two claws
2 two claws
5 dust cove
r
5 flexible flat cable
(32core) (from optical device
)
1 two step screws
2 two screws
((2X9) (G with), +p tappin)
6 optical pick-up
(KRM-220CAA)
3 two insulators (main)
4 two insulators (main)
