18
RCD-W10
SECTION 4
TEST MODE
Setting the Test Mode
Procedure:
1. Press the POWER button to POWER on.
2. Press the l AMS L (DECK A), [SBM] and l AMS
L (DECK B) buttons in order without releasing the button.
3. Turn the l AMS L (DECK B) knob to select the menu.
4. Press the l AMS L (DECK B) knob to execute the test
mode.
Releasing the Test Mode
Procedure 1:
1. Turn the l AMS L (DECK B) knob to select the Ship
Mode.
2. Press the l AMS L (DECK B) knob to execute the Ship
Mode.
3. Press the POWER button to POWER off.
Procedure 2:
1. Press the l AMS L (DECK A), [SBM] and l AMS
L (DECK B) buttons in order without releasing the button.
2. Press the POWER button to POWER off.
Contents of test mode
No. Display Function
1 SYS Version System version display
2 CDR Version CDR version display
3BU Test Deck A BU test mode
4 SERVICE Deck A Service mode
5 Ship Mode CD Shipment mode
6 FL ALL ON Fluorescent indicator tube test
7 FL ALL OFF Fluorescent indicator tube test
8 FL ITIMATSU Fluorescent indicator tube test
9 LED CHECK LED check
10 KEY CHECK Keyboard check
11 RM CHECK Remote commander check
12 CDR History CDR error history display
13 Play Speed Deck A x4 speed
System Version Display
Procedure:
1. Enter the test mode, then turn the l AMS L (DECK B)
knob to display “SYS Version”, and press the l AMS L
(DECK B) knob.
2. The system version is displayed.
3. To exit from this mode, turn the l AMS L (DECK B)
knob to display “Ship Mode”, and press the l AMS L
(DECK B) knob to execute the Ship Mode.
4. Press the POWER button to POWER off.
CDR Version Display
Procedure:
1. Enter the test mode, then turn the l AMS L (DECK B)
knob to display “CDR Version”, and press the l AMS L
(DECK B) knob.
2. The CDR version is displayed.
3. To exit from this mode, turn the l AMS L (DECK B)
knob to display “Ship Mode”, and press the l AMS L
(DECK B) knob to execute the Ship Mode.
4. Press the POWER button to POWER off.
BU Test Mode (Deck A)
Procedure:
1. Enter the test mode, then turn the l AMS L (DECK B)
knob to display “BU Test”, and press the l AMS L
(DECK B) knob.
2. “bdt S CURVE” is displayed. This test mode is used in the Elec-
trical Adjustment section.
3. Turn the l AMS L (DECK B) knob. “bdt RAM READ”,
“bdt RAM WRITE”, “bdt COMOUT”, “bdt FB TUNE” and “bdt
ERR RATE” are displayed.
4. To exit from this mode, press the MENU/NO button and turn
the l AMS L (DECK B) knob to display “bdt ERR
RATE”.
5. Press the l AMS L (DECK A), [SBM] and l AMS
L (DECK B) buttons in order without releasing the button.
6. Press the POWER button to POWER off.
Service Mode (Deck A)
Procedure:
1. Enter the test mode, then turn the l AMS L (DECK B)
knob to display “SERVICE”, and press the l AMS L
(DECK B) knob.
2. “SERVICE MODE” is displayed.
3. Press the ERASE button, the “SLED OUT” is displayed and
the sled moves to the outermost position.
4. Press the FINALIZE button, the “SLED IN” is displayed and
the sled moves to the innermost position.
5. Press the l AMS L (DECK B) knob, then “SERVICE
MODE” is displayed again.
6. To exit from this mode, press the l AMS L (DECK A),
[SBM] and l AMS L (DECK B) buttons in order with-
out releasing the button.
7. Press the POWER button to POWER off.
Note: Always move the pick-up to the most inside position when
exiting from this mode.
Ship Mode
Procedure:
1. Enter the test mode, then turn the l AMS L (DECK B)
knob to display “Ship Mode”, and press the l AMS L
(DECK B) knob.
2. “Push POWER!” is displayed.
3. Press the POWER button to POWER off.
FL ALL ON Mode
Procedure:
1. Enter the test mode, then turn the l AMS L (DECK B)
knob to display “FL ALL ON”, and press the l AMS L
(DECK B) knob.
2. All segments of fluorescent indicator tube and LED turn on.
3. Press the MENU/NO button, then “FL ALL ON” is displayed
again.
4. To exit from this mode, turn the l AMS L (DECK B)
knob to display “Ship Mode”, and press the l AMS L
(DECK B) knob to execute the Ship Mode.
5. Press the POWER button to POWER off.
