Sony RCD-W10 - BD Board; Optical Block Section

15
RCD-W10
3-15. BD Board
3-16. Optical Block Section
1 Remove soldering from the four points.
3 BD board
2 flexible flat cable
(16core)
1 floating screw
4 optical block section
3 shaft (BU holder)
2
Rotate the cam (66) in the direction of 2 to move
the shaft (BU holder) upper.
cam (66)
