RCD-W10
6-2. Printed Wiring Board – BD Section –
• : Uses unleaded solder.
• See page 53 for Circuit Boards Location.
IC201
IC101
IC104
IC102
IC103
IC105
C
1
3
(A-MAX.3)
(Page 65)
MAIN
TP
(RFAC)
TP
(DVC)
TP
(TE)
TP
(FE)
Ref. No. Location
IC101 B-2
IC102 C-1
IC103 B-3
IC104 C-2
IC105 B-7
IC201 A-2
Q101 A-3
• Semiconductor
Location
