RCD-W10
6-11. Printed Wiring Board – MAIN Section (Side B) –
• : Uses unleaded solder.
• See page 53 for Circuit Boards Location.
IC 450
IC 410
IC 430
IC 420
IC 620
IC 440
IC 460
IC 800
IC 610
1
5
CN151
M151
(LOADING)
910 11
CN680
C805
1
18
5
M
S272
LOADING
IN
S271
LOADING
OUT
1-645-721-
21
(21)
LOADING BOARD
69
59
69
Ref. No. Location
D401 D-4
D402 D-4
D403 D-4
D404 D-4
D411 E-4
D412 E-4
D421 D-4
D422 D-4
D431 F-4
D432 E-4
D433 E-4
D434 E-4
D451 F-3
D452 F-3
D453 F-3
D454 F-3
D461 D-4
IC410 F-3
IC420 D-5
IC430 F-4
IC440 F-5
IC450 F-2
IC460 C-4
IC610 F-6
IC620 F-5
IC800 A-2
Q310 E-7
• Semiconductor
Location

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
