Sony RCD-W10 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
92
RCD-W10
C135 1-162-959-11 CERAMIC CHIP 330PF 5% 50V
C136 1-126-391-11 ELECT CHIP 47uF 20.00% 6.3V
C137 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C138 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C139 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C140 1-126-390-11 ELECT CHIP 22uF 20.00% 6.3V
C141 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C142 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C143 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C144 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C145 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C146 1-128-934-91 CERAMIC CHIP 0.33uF 20% 10V
C150 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C151 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C156 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C157 1-126-390-11 ELECT CHIP 22uF 20.00% 6.3V
C158 1-126-390-11 ELECT CHIP 22uF 20.00% 6.3V
C160 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C178 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C179 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C180 1-126-395-11 ELECT 22uF 20% 16V
C181 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C182 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C183 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C184 1-126-395-11 ELECT 22uF 20% 16V
C185 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C186 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C187 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C188 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C189 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C190 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C191 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C192 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C193 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C194 1-126-395-11 ELECT 22uF 20% 16V
C200 1-126-390-11 ELECT CHIP 22uF 20.00% 6.3V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-126-392-11 ELECT CHIP 100uF 20.00% 6.3V
C203 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C204 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C205 1-126-391-11 ELECT CHIP 47uF 20.00% 6.3V
C206 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C207 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C208 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C209 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C210 1-126-392-11 ELECT CHIP 100uF 20.00% 6.3V
C212 1-126-390-11 ELECT CHIP 22uF 20.00% 6.3V
C213 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C214 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C217 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C218 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C219 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C220 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C221 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C222 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C223 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C224 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C225 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C226 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C227 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C228 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C230 1-162-912-11 CERAMIC CHIP 7PF 0.5PF 50V
C232 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C233 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C234 1-165-908-91 CERAMIC CHIP 1uF 10% 10V
C235 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C236 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C237 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C238 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C239 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C240 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C241 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C242 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C244 1-126-390-11 ELECT CHIP 22uF 20.00% 6.3V
C245 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C246 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C247 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C248 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C249 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C250 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C251 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C254 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C257 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C258 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C259 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C260 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C262 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C263 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C268 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C269 1-126-392-11 ELECT CHIP 100uF 20.00% 6.3V
C270 1-126-396-11 ELECT CHIP 47uF 20.00% 16V
C271 1-126-392-11 ELECT CHIP 100uF 20.00% 6.3V
C272 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C273 1-126-391-11 ELECT CHIP 47uF 20.00% 6.3V
C275 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C289 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C302 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C304 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C501 1-126-396-11 ELECT CHIP 47uF 20.00% 16V
C502 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C506 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C508 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C509 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C510 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C511 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C512 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C513 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C514 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C517 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C518 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C519 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C520 1-164-156-11 CERAMIC CHIP 0.1uF 25V
CDR

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
