Sony RDR GX7 Service Manual

5-2E
Pin No.
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
Pin Name
H DET
DSEL(CMUTE)
Syncro Power
YC SEP ON
S2SW
L1 SEL
XP MUTE
BDVV
BVSS
MAIN/SAP
SAP DET
JUST CLK
AUTO PRESET
TA MUTE
TU PCONT
TU V DET
INSEL1
INSEL2
INSEL TU
FAN SPEED
FAN ONOFF
RELAY CONT
IDET
AVDD
AVSS
Avref
AREA
FAN DET
KEY1
KEY2
KEY3
KEY4
KEY5
TU AFT
EURO 8DET
STEREO DET
AGC
ONDO
iMute
P FAIL
IT REQ
SYNC V
XPDCDAV
AV LINK IN
UVIC BUSY
TTXT ENABLE
TTXT SDA
WIDE
TTXT SCL
SIN
I/O
I
I
I
I
Function
With sync / no sync
Mute of C+ signal
Power supply ON during Syncro standby
YC sep circuit ON/OFF
With S PIN input
Audio mute
Sound multiplex MSP
Tuner power supply control
With V sync/no V sync
Output switching
Output switching
Output switching
Speed switching
FAN ON/OFF
AC relay ON/OFF
With L3 Icont/no L3 Icont
Abbreviation
FAN stopping detection
L3 8PIN input
Tuner gain
Temperature detection
Mute ICONT signal
AC off detection
Request input from SH
V sync input
PDC data reception OK
AV LINK input
TTXT data
Wide switching
TTNT clock
Serial data input

Sony RDR GX7 Specifications

General

I/O ports	Analog AV In/Out S-Video In/Out Component Video Out DV Terminal (i.LINK) 2 x Scart (1 including RGB in) Digital Audio Out
