Sony RDR GX7 Service Manual

8-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
0 sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
8-4
* A-6071-051-A AV-071 (U) BOARD, COMPLETE
*************************
< BUZZER >
BZ601 1-544-886-11 BUZZER
< CAPACITOR >
C101 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C104 1-126-964-11 ELECT 10uF 20.00% 50V
C108 1-126-947-11 ELECT 47uF 20.00% 16V
C109 1-126-947-11 ELECT 47uF 20.00% 16V
C110 1-126-947-11 ELECT 47uF 20.00% 16V
C111 1-126-947-11 ELECT 47uF 20.00% 16V
C115 1-126-947-11 ELECT 47uF 20.00% 25V
C117 1-126-947-11 ELECT 47uF 20.00% 16V
C208 1-126-947-11 ELECT 47uF 20.00% 16V
C209 1-126-947-11 ELECT 47uF 20.00% 16V
C210 1-126-947-11 ELECT 47uF 20.00% 16V
C211 1-126-947-11 ELECT 47uF 20.00% 16V
C212 1-126-963-11 ELECT 4.7uF 20.00% 50V
C218 1-126-963-11 ELECT 4.7uF 20.00% 50V
C220 1-126-947-11 ELECT 47uF 20.00% 16V
C221 1-126-947-11 ELECT 47uF 20.00% 16V
C222 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C223 1-126-964-11 ELECT 10uF 20.00% 50V
C224 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C226 1-126-947-11 ELECT 47uF 20.00% 16V
C227 1-126-961-11 ELECT 2.2uF 20.00% 50V
C228 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C235 1-126-947-11 ELECT 47uF 20.00% 16V
C236 1-126-964-11 ELECT 10uF 20.00% 50V
C301 1-126-947-11 ELECT 47uF 20.00% 25V
C302 1-126-924-11 ELECT 330uF 20.00% 6.3V
C308 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-126-947-11 ELECT 47uF 20.00% 16V
C313 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C314 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C315 1-126-947-11 ELECT 47uF 20.00% 16V
C323 1-107-737-11 MYLAR 560PF 5.00% 50V
C324 1-107-737-11 MYLAR 560PF 5.00% 50V
C326 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C329 1-130-472-00 MYLAR 0.0012uF 5% 50V
C330 1-130-472-00 MYLAR 0.0012uF 5% 50V
C331 1-126-960-11 ELECT 1uF 20.00% 50V
C338 1-126-947-11 ELECT 47uF 20.00% 16V
C340 1-126-947-11 ELECT 47uF 20.00% 16V
C343 1-126-947-11 ELECT 47uF 20.00% 16V
C344 1-126-947-11 ELECT 47uF 20.00% 16V
C347 1-104-987-11 MYLAR 0.001uF 5.00% 200V
C348 1-104-987-11 MYLAR 0.001uF 5.00% 200V
C349 1-104-987-11 MYLAR 0.001uF 5.00% 50V
C350 1-104-987-11 MYLAR 0.001uF 5.00% 50V
C351 1-106-351-00 MYLAR 2200PF 5% 200V
C352 1-106-351-00 MYLAR 2200PF 5% 200V
C353 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C354 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C355 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C356 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C357 1-126-934-11 ELECT 220uF 20.00% 16V
C358 1-126-947-11 ELECT 47uF 20.00% 16V
C359 1-126-947-11 ELECT 47uF 20.00% 16V
C360 1-126-947-11 ELECT 47uF 20.00% 16V
C361 1-126-947-11 ELECT 47uF 20.00% 16V
C362 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C363 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C364 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C367 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C368 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C369 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C370 1-164-217-11 CERAMIC CHIP 150PF 5.00% 50V
C401 1-126-964-11 ELECT 10uF 20.00% 50V
C402 1-126-964-11 ELECT 10uF 20.00% 50V
C404 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C409 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C412 1-126-947-11 ELECT 47uF 20.00% 16V
C413 1-126-947-11 ELECT 47uF 20.00% 16V
C414 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C415 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C416 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C418 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C419 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C422 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C429 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C430 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C431 1-126-947-11 ELECT 47uF 20.00% 16V
C432 1-104-665-11 ELECT 100uF 20.00% 10V
C436 1-126-963-11 ELECT 4.7uF 20.00% 50V
C437 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C438 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C439 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
AV-071

Sony RDR GX7 Specifications

General

I/O ports	Analog AV In/Out S-Video In/Out Component Video Out DV Terminal (i.LINK) 2 x Scart (1 including RGB in) Digital Audio Out
