6-4. Service Mode. Menu Items and Description
1) When the key ‘1’ is pressed down, the monitor display moves
to the device check menu screen.
2) When the key ‘2’ is pressed down, the monitor display moves
to the path check menu screen between devices.
3) When the key ‘3’ is pressed down, the monitor display moves
to the version check screen.
6-5. Device Check Menu (1/2)
0) When the key ‘0’ is pressed down, all devices are checked
automatically.
1) When the key ‘1’ is pressed down, the VIDEOENC device check
will be executed.
2) When the key ‘2’ is pressed down, the IPCONV device check
will be executed. (This item is not installed in the EURO models,
NG is displayed but it is not indicating any default of the main
unit.)
3) When the key ‘3’ is pressed down, the TL750 device check
will be executed.
4) When the key ‘4’ is pressed down, the GTR device check will
be executed.
5) When the key ‘5’ is pressed down, the FBI device check will
be executed.
6) When the key ‘6’ is pressed down, the VIDEODEC device check
will be executed.
7) When the key ‘7’ is pressed down, the AVENC device check
will be executed.
8) When the key ‘8’ is pressed down, the MSP device check will
be executed.
9) When the key ‘9’ is pressed down, the AVDEC device check
will be executed.
10) When the key ‘t’ is pressed down, the monitor display moves
to the next path check menu screen.
6-6. Device Check Menu (2/2)
1) When the key ‘1’ is pressed down, the DV device check will be
executed.
2) When the key ‘2’ is pressed down, the CPRM device check
will be executed.
3) When the key ‘3’ is pressed down, the CCM device check will
be executed.
4) When the key ‘4’ is pressed down, the EPGSLICER device
check will be executed. (This item is not installed in the EURO
models, NG is displayed but it is not indicating any default of
the main unit.)
5) When the key ‘5’ is pressed down, the GEMSTAR device check
will be executed. (This item is not installed in the EURO models,
NG is displayed but it is not indicating any default of the main
unit.)
6) When the key ‘T’ is pressed down, the monitor display returns
to the previous device check menu screen.
<< MAIN MENU >>
1) DEVICE TEST
2) PATH TEST
3) TEST MODE
<< DEVICE TEST MENU 1/2 >>
0) ALL CHECK
1) VIDEO
2) IPCONV
ENC
3) TL750
4) GTR
5) FBI
6) VIDEO DEC
7) AVENC
8) MSP
t
9) AVDEC
MENU 2
<< DEVICE 2/2TEST MENU >>
1) DV
2) CPRM
3) CCM
4) EPGSLICER
T
5) GEMSTAR
MENU 1
