Sony RDR GX7 Service Manual

8-5
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
C440 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C441 1-126-947-11 ELECT 47uF 20.00% 16V
C444 1-126-963-11 ELECT 4.7uF 20.00% 50V
C447 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C448 1-126-947-11 ELECT 47uF 20.00% 35V
C469 1-162-925-11 CERAMIC CHIP 68PF 5.00% 50V
C603 1-126-947-11 ELECT 47uF 20.00% 16V
C604 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C605 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C608 1-126-935-11 ELECT 470uF 20.00% 6.3V
C610 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C611 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C612 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C613 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C614 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C615 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C616 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C618 1-126-916-11 ELECT 1000uF 20.00% 6.3V
C619 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C620 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C621 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C622 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C623 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C624 1-115-456-21 CAPACITOR 0.22F 5.5V
C627 1-126-935-11 ELECT 470uF 20.00% 6.3V
C628 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C631 1-126-934-11 ELECT 220uF 20.00% 16V
C632 1-163-024-00 CERAMIC CHIP 0.018uF 10.00% 50V
C633 1-163-024-00 CERAMIC CHIP 0.018uF 10.00% 50V
C634 1-100-566-91 CERAMIC CHIP 0.1uF 10.00% 25V
C635 1-126-965-91 ELECT 22uF 20.00% 50V
C636 1-115-339-11 CERAMIC CHIP 0.1uF 10.00% 50V
C638 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C639 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C640 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C642 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C643 1-163-022-00 CERAMIC CHIP 0.012uF 10% 50V
C644 1-163-021-91 CERAMIC CHIP 0.01uF 10.00% 50V
C701 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C704 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C705 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C706 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C708 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C709 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C711 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C715 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C716 1-126-947-11 ELECT 47uF 20.00% 16V
C717 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C720 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C724 1-126-947-11 ELECT 47uF 20.00% 16V
C726 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C728 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C735 1-126-947-11 ELECT 47uF 20.00% 16V
C738 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C739 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C740 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C741 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C743 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C745 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C746 1-126-947-11 ELECT 47uF 20.00% 16V
C748 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C753 1-126-947-11 ELECT 47uF 20.00% 16V
C754 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C763 1-126-961-11 ELECT 2.2uF 20.00% 50V
C764 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C765 1-164-172-11 CERAMIC CHIP 0.0056uF 10.00% 25V
C766 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C801 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C802 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C804 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C805 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C806 1-126-947-11 ELECT 47uF 20.00% 16V
C807 1-126-947-11 ELECT 47uF 20.00% 16V
C808 1-126-947-11 ELECT 47uF 20.00% 16V
C811 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C814 1-126-947-11 ELECT 47uF 20.00% 16V
C815 1-126-947-11 ELECT 47uF 20.00% 16V
C816 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C817 1-126-947-11 ELECT 47uF 20.00% 16V
C818 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C819 1-126-935-11 ELECT 470uF 20.00% 6.3V
C820 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C821 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C1101 1-128-551-11 ELECT 22uF 20.00% 25V
C1103 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1104 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1105 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1106 1-126-964-11 ELECT 10uF 20.00% 50V
C1107 1-128-551-11 ELECT 22uF 20.00% 25V
C1108 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1109 1-126-960-11 ELECT 1uF 20.00% 50V
C1110 1-128-551-11 ELECT 22uF 20.00% 25V
C1111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C1112 1-126-964-11 ELECT 10uF 20.00% 50V
C1113 1-126-964-11 ELECT 10uF 20.00% 50V
C1114 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C1116 1-162-920-11 CERAMIC CHIP 27PF 5% 50V
C1117 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C1118 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C1119 1-164-230-11 CERAMIC CHIP 220PF 5.00% 50V
C1120 1-126-964-11 ELECT 10uF 20.00% 50V
C1121 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
< CONNECTOR >
CN101 1-778-317-11 CONNECTOR, BOARD TO BOARD 13P
CN102 1-794-509-11 PIN, CONNECTOR (PC BOARD) (3P)
CN602 1-779-937-11 CONNECTOR, FFC/FPC 19P
CN801 1-573-489-11 PIN, CONNECTOR (PC BOARD) 11P
< DIODE >
D302 8-719-075-77 DIODE EC10DA40-TE12
D303 8-719-914-44 DIODE DAP202K-T-146
D351 8-719-914-43 DIODE DAN202K-T-146
D408 8-719-988-61 DIODE 1SS355TE-17
D411 8-719-058-24 DIODE RB501V-40TE-17
AV-071
