Sony RDR GX7 Service Manual

8-6
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
D602 8-719-075-77 DIODE EC10DA40-TE12
D603 8-719-075-77 DIODE EC10DA40-TE12
D605 8-719-988-61 DIODE 1SS355TE-17
D606 8-719-988-61 DIODE 1SS355TE-17
D607 8-719-988-61 DIODE 1SS355TE-17
D608 8-719-988-61 DIODE 1SS355TE-17
D609 8-719-083-85 DIODE UDZS-TE17-22B
D610 8-719-422-62 DIODE MA8062-L-TX
D611 8-719-914-43 DIODE DAN202K-T-146
D612 8-719-017-58 DIODE MA8068-TX
D705 8-719-988-61 DIODE 1SS355TE-17
D706 8-719-988-61 DIODE 1SS355TE-17
D707 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-071-15 DIODE HZM6.8ZWA1TL
D802 8-719-071-15 DIODE HZM6.8ZWA1TL
D803 8-719-071-15 DIODE HZM6.8ZWA1TL
D807 8-719-071-15 DIODE HZM6.8ZWA1TL
D808 8-719-071-15 DIODE HZM6.8ZWA1TL
D809 8-719-071-15 DIODE HZM6.8ZWA1TL
D810 8-719-071-15 DIODE HZM6.8ZWA1TL
D811 8-719-071-15 DIODE HZM6.8ZWA1TL
D812 8-719-071-15 DIODE HZM6.8ZWA1TL
D813 8-719-071-15 DIODE HZM6.8ZWA1TL
D1201 8-719-071-15 DIODE HZM6.8ZWA1TL
D1202 8-719-071-15 DIODE HZM6.8ZWA1TL
< FERRITE BEAD >
FB301 1-414-766-22 FERRITE 0uH
FB302 1-414-766-22 FERRITE 0uH
FB303 1-414-766-22 FERRITE 0uH
FB304 1-414-766-22 FERRITE 0uH
FB801 1-414-230-22 FERRITE 0uH
FB802 1-414-230-22 FERRITE 0uH
< FILTER >
FL601 1-233-893-21 FILTER, CHIP EMI
FL801 1-233-893-21 FILTER, CHIP EMI
FL802 1-233-893-21 FILTER, CHIP EMI
FL803 1-233-893-21 FILTER, CHIP EMI
FL804 1-233-893-21 FILTER, CHIP EMI
< IC >
IC101 8-759-521-89 IC PQ20WZ5U
IC102 6-703-758-01 IC PQ050DZ01ZPH
IC105 8-759-521-89 IC PQ20WZ5U
IC106 6-703-756-01 IC PQ1L503M2SPQ
IC201 6-703-503-01 IC AK5365VQ
IC301 6-701-565-01 IC CXD9627A-E2
IC302 8-759-052-52 IC NJM78M05DL1A-TE1
IC303 8-759-909-71 IC BA4558F-E2
IC304 8-759-909-71 IC BA4558F-E2
IC402 8-759-712-65 IC PQ070XZ01ZP
IC406 6-703-750-01 IC TK11850L-1TL
IC603 6-702-767-01 IC BD4745G-TR
IC604 6-703-873-01 IC PST3241NL
IC605 6-704-473-01 IC uPD703033BYGF-M29-3BA-A
IC701 6-703-155-01 IC LA73030-TLM-E
IC801 8-759-667-17 IC L79M05TLL-SONY-TL
IC802 6-701-820-01 IC LA73053-TLM-E
IC1101 8-759-349-01 IC MC68HC68VBIFB
< JACK >
J601 1-764-188-21 JACK (SMALL TYPE) (DIA. 3.5)
J801 1-785-535-11 JACK BLOCK, PIN
J802 1-785-535-11 JACK BLOCK, PIN
J805 1-815-360-11 JACK, PIN 3P (COMPONENT OUT)
< JUMPER RESISTOR >
JR001 1-216-295-91 SHORT CHIP 0
JR002 1-216-296-11 SHORT CHIP 0
JR003 1-216-296-11 SHORT CHIP 0
JR004 1-216-296-11 SHORT CHIP 0
JR005 1-216-295-91 SHORT CHIP 0
JR006 1-216-295-91 SHORT CHIP 0
JR007 1-216-296-11 SHORT CHIP 0
JR008 1-216-296-11 SHORT CHIP 0
JR009 1-216-296-11 SHORT CHIP 0
JR010 1-216-296-11 SHORT CHIP 0
JR011 1-216-296-11 SHORT CHIP 0
JR012 1-216-295-91 SHORT CHIP 0
JR013 1-216-296-11 SHORT CHIP 0
JR014 1-216-295-91 SHORT CHIP 0
JR015 1-216-296-11 SHORT CHIP 0
< COIL >
L401 1-469-967-21 INDUCTOR 10uH
L402 1-469-967-21 INDUCTOR 10uH
L404 1-469-967-21 INDUCTOR 10uH
L406 1-414-187-11 INDUCTOR 47uH
L407 1-414-187-11 INDUCTOR 47uH
L409 1-414-187-11 INDUCTOR 47uH
L411 1-414-187-11 INDUCTOR 47uH
L412 1-410-431-11 INDUCTOR 100uH
L601 1-412-755-11 INDUCTOR 47uH
L701 1-469-967-21 INDUCTOR 10uH
L702 1-469-967-21 INDUCTOR 10uH
L703 1-469-967-21 INDUCTOR 10uH
L801 1-419-387-21 INDUCTOR 100uH
L802 1-419-387-21 INDUCTOR 100uH
L803 1-400-145-21 INDUCTOR 47uH
L1101 1-469-967-21 INDUCTOR 10uH
L1102 1-469-967-21 INDUCTOR 10uH
L1103 1-469-967-21 INDUCTOR 10uH
L1104 1-400-145-21 INDUCTOR 47uH
< IC LINK >
PS101 1-576-509-21 IC LINK 1A 50V
PS102 1-576-508-21 IC LINK 0.7A 50V
PS401 1-576-259-11 IC LINK 0.7A 50V
< TRANSISTOR >
Q103 8-729-421-19 TRANSISTOR UN2213-TX
Q107 8-729-424-08 TRANSISTOR UN2111-TX
Q108 8-729-048-28 TRANSISTOR 2SD1766-T100-QR
Q301 8-729-045-17 TRANSISTOR 2SB1561T100Q
Q302 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q303 8-729-045-17 TRANSISTOR 2SB1561T100Q
Q304 8-729-421-19 TRANSISTOR UN2213-TX
Q306 8-729-027-53 TRANSISTOR DTC124TKA-T146
Q308 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q310 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
AV-071
