Sony RDR GX7 Service Manual

8-7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
Q311 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q312 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q313 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q314 8-729-424-18 TRANSISTOR UN2113-TX
Q315 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q316 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q317 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q404 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q406 8-729-421-19 TRANSISTOR UN2213-TX
Q408 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q409 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q410 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q412 8-729-421-22 TRANSISTOR UN2211-TX
Q414 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q415 8-729-421-22 TRANSISTOR UN2211-TX
Q416 8-729-045-17 TRANSISTOR 2SB1561T100Q
Q420 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q606 8-729-421-22 TRANSISTOR UN2211-TX
Q607 8-729-424-08 TRANSISTOR UN2111-TX
Q608 8-729-921-73 TRANSISTOR 2SD1781K-T146-QR
Q609 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q610 8-729-056-46 TRANSISTOR 2SC5053T100Q
Q611 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q612 8-729-424-18 TRANSISTOR UN2113-TX
Q613 8-729-421-19 TRANSISTOR UN2213-TX
Q705 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q706 8-729-424-59 TRANSISTOR UN2212-TX
Q708 8-729-045-17 TRANSISTOR 2SB1561T100Q
Q709 8-729-120-28 TRANSISTOR 2SC2412K-T-146-QR
Q710 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q711 8-729-026-49 TRANSISTOR 2SA1037AK-T146-QR
Q712 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q713 8-729-216-22 TRANSISTOR 2SA1162-YG-TE85L
Q715 8-729-230-49 TRANSISTOR 2SC2712-YG-TE85L
Q716 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q801 8-729-424-08 TRANSISTOR UN2111-TX
Q802 8-729-048-28 TRANSISTOR 2SD1766-T100-QR
Q809 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q810 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q811 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q812 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q813 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q814 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q815 8-729-421-19 TRANSISTOR UN2213-TX
Q816 8-729-424-08 TRANSISTOR UN2111-TX
Q1101 8-729-402-81 TRANSISTOR XN4501-TW
Q1102 8-729-402-81 TRANSISTOR XN4501-TW
Q1103 8-729-422-27 TRANSISTOR 2SD601A-QRS-TX
Q1104 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
Q1105 8-729-424-02 TRANSISTOR 2SB709A-QRS-TX
< RESISTOR >
R104 1-218-857-11 METAL CHIP 2.7K 0.5% 1/16W
R105 1-218-849-11 METAL CHIP 1.2K 0.5% 1/16W
R106 1-218-849-11 METAL CHIP 1.2K 5% 1/16W
R108 1-216-864-11 METAL CHIP 0 5% 1/16W
R111 1-216-864-11 METAL CHIP 0 5% 1/16W
R112 1-216-210-00 RES-CHIP 3.3K 5% 1/8W
R113 1-216-833-11 METAL CHIP 10K 5% 1/16W
R114 1-216-296-11 SHORT CHIP 0
R115 1-216-296-11 SHORT CHIP 0
R116 1-216-295-91 SHORT CHIP 0
R117 1-216-295-91 SHORT CHIP 0
R118 1-216-295-91 SHORT CHIP 0
R120 1-216-296-11 SHORT CHIP 0
R121 1-216-295-91 SHORT CHIP 0
R123 1-208-818-11 METAL CHIP 33K 0.5% 1/10W
R124 1-208-808-11 METAL CHIP 12K 0.5% 1/10W
R125 1-216-665-11 METAL CHIP 3.9K 0.5% 1/10W
R126 1-216-833-11 METAL CHIP 10K 5% 1/16W
R127 1-216-295-91 SHORT CHIP 0
R128 1-208-810-11 METAL CHIP 15K 0.5% 1/10W
R129 1-216-296-11 SHORT CHIP 0
R130 1-216-296-11 SHORT CHIP 0
R131 1-216-864-11 METAL CHIP 0 5% 1/16W
R132 1-216-210-00 RES-CHIP 3.3K 5% 1/8W
R135 1-216-296-11 SHORT CHIP 0
R137 1-216-296-11 SHORT CHIP 0
R209 1-216-864-11 METAL CHIP 0 5% 1/16W
R210 1-216-864-11 METAL CHIP 0 5% 1/16W
R214 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R215 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R216 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R217 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R218 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R220 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R221 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R222 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R224 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R227 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R248 1-216-833-11 METAL CHIP 10K 5% 1/16W
R250 1-216-833-11 METAL CHIP 10K 5% 1/16W
R253 1-216-833-11 METAL CHIP 10K 5% 1/16W
R255 1-216-809-11 METAL CHIP 100 5% 1/16W
R256 1-216-801-11 METAL CHIP 22 5% 1/16W
R257 1-216-797-11 METAL CHIP 10 5% 1/16W
R258 1-216-801-11 METAL CHIP 22 5% 1/16W
R277 1-216-809-11 METAL CHIP 100 5% 1/16W
R278 1-216-837-11 METAL CHIP 22K 5% 1/16W
R279 1-216-837-11 METAL CHIP 22K 5% 1/16W
R280 1-216-837-11 METAL CHIP 22K 5% 1/16W
R301 1-216-849-11 METAL CHIP 220K 5% 1/16W
R302 1-216-817-11 METAL CHIP 470 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R307 1-216-833-11 METAL CHIP 10K 5% 1/16W
R308 1-216-845-11 METAL CHIP 100K 5% 1/16W
R309 1-216-830-11 METAL CHIP 5.6K 5% 1/16W
R310 1-216-801-11 METAL CHIP 22 5% 1/16W
R311 1-216-809-11 METAL CHIP 100 5% 1/16W
R313 1-216-809-11 METAL CHIP 100 5% 1/16W
R320 1-216-049-11 RES-CHIP 1K 5% 1/10W
R322 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R323 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R324 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R325 1-218-869-11 METAL CHIP 8.2K 0.5% 1/10W
R326 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R327 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
AV-071

Sony RDR GX7 Specifications

General

I/O ports	Analog AV In/Out S-Video In/Out Component Video Out DV Terminal (i.LINK) 2 x Scart (1 including RGB in) Digital Audio Out
