Sony RDR GX7 Service Manual

8-9
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R638 1-216-833-11 METAL CHIP 10K 5% 1/16W
R639 1-216-833-11 METAL CHIP 10K 5% 1/16W
R640 1-216-864-11 METAL CHIP 0 5% 1/16W
R641 1-216-864-11 METAL CHIP 0 5% 1/16W
R642 1-216-833-11 METAL CHIP 10K 5% 1/16W
R645 1-216-864-11 METAL CHIP 0 5% 1/16W
R646 1-216-210-00 RES-CHIP 3.3K 5% 1/8W
R647 1-216-864-11 METAL CHIP 0 5% 1/16W
R648 1-216-833-11 METAL CHIP 10K 5% 1/16W
R650 1-216-809-11 METAL CHIP 100 5% 1/16W
R651 1-216-864-11 METAL CHIP 0 5% 1/16W
R652 1-216-809-11 METAL CHIP 100 5% 1/16W
R653 1-216-864-11 METAL CHIP 0 5% 1/16W
R654 1-216-809-11 METAL CHIP 100 5% 1/16W
R655 1-216-833-11 METAL CHIP 10K 5% 1/16W
R657 1-216-809-11 METAL CHIP 100 5% 1/16W
R658 1-216-824-11 METAL CHIP 1.8K 5% 1/16W
R659 1-216-809-11 METAL CHIP 100 5% 1/16W
R661 1-216-833-11 METAL CHIP 10K 5% 1/16W
R663 1-216-832-11 METAL CHIP 8.2K 5% 1/16W
R665 1-216-833-11 METAL CHIP 10K 5% 1/16W
R672 1-216-210-00 RES-CHIP 3.3K 5% 1/8W
R673 1-216-809-11 METAL CHIP 100 5% 1/16W
R674 1-216-809-11 METAL CHIP 100 5% 1/16W
R675 1-216-833-11 METAL CHIP 10K 5% 1/16W
R676 1-216-809-11 METAL CHIP 100 5% 1/16W
R677 1-216-809-11 METAL CHIP 100 5% 1/16W
R678 1-216-809-11 METAL CHIP 100 5% 1/16W
R679 1-216-809-11 METAL CHIP 100 5% 1/16W
R680 1-216-809-11 METAL CHIP 100 5% 1/16W
R681 1-216-809-11 METAL CHIP 100 5% 1/16W
R682 1-216-809-11 METAL CHIP 100 5% 1/16W
R683 1-216-809-11 METAL CHIP 100 5% 1/16W
R684 1-216-841-11 METAL CHIP 47K 5% 1/16W
R685 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R687 1-216-833-11 METAL CHIP 10K 5% 1/16W
R688 1-216-833-11 METAL CHIP 10K 5% 1/16W
R689 1-216-296-11 SHORT CHIP 0
R690 1-216-833-11 METAL CHIP 10K 5% 1/16W
R691 1-216-833-11 METAL CHIP 10K 5% 1/16W
R694 1-216-833-11 METAL CHIP 10K 5% 1/16W
R695 1-208-798-11 METAL CHIP 4.7K 0.5% 1/10W
R697 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R698 1-216-821-11 METAL CHIP 1K 5% 1/16W
R699 1-216-208-00 RES-CHIP 2.7K 5% 1/8W
R700 1-216-838-11 METAL CHIP 27K 5% 1/16W
R702 1-216-864-11 METAL CHIP 0 5% 1/16W
R712 1-216-864-11 METAL CHIP 0 5% 1/16W
R715 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R716 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R717 1-216-833-11 METAL CHIP 10K 5% 1/16W
R718 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R719 1-216-864-11 METAL CHIP 0 5% 1/16W
R720 1-216-815-11 METAL CHIP 330 5% 1/16W
R721 1-216-864-11 METAL CHIP 0 5% 1/16W
R723 1-216-821-11 METAL CHIP 1K 5% 1/16W
R724 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R725 1-216-864-11 METAL CHIP 0 5% 1/16W
R726 1-216-864-11 METAL CHIP 0 5% 1/16W
R727 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R728 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R729 1-216-822-11 METAL CHIP 1.2K 5% 1/16W
R730 1-216-826-11 METAL CHIP 2.7K 5% 1/16W
R731 1-216-817-11 METAL CHIP 470 5% 1/16W
R732 1-216-828-11 METAL CHIP 3.9K 5% 1/16W
R733 1-216-857-11 METAL CHIP 1M 5% 1/16W
R734 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R735 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R742 1-216-821-11 METAL CHIP 1K 5% 1/16W
R743 1-216-839-11 METAL CHIP 33K 5% 1/16W
R744 1-216-833-11 METAL CHIP 10K 5% 1/16W
R745 1-216-819-11 METAL CHIP 680 5% 1/16W
R746 1-216-813-11 METAL CHIP 220 5% 1/16W
R747 1-216-813-11 METAL CHIP 220 5% 1/16W
R748 1-216-857-11 METAL CHIP 1M 5% 1/16W
R749 1-218-289-11 METAL CHIP 510 5% 1/10W
R751 1-218-850-11 METAL CHIP 1.3K 5% 1/10W
R752 1-216-864-11 METAL CHIP 0 5% 1/16W
R753 1-216-864-11 METAL CHIP 0 5% 1/16W
R755 1-216-296-11 SHORT CHIP 0
R756 1-218-289-11 METAL CHIP 510 5% 1/10W
R764 1-216-821-11 METAL CHIP 1K 5% 1/16W
R765 1-216-864-11 METAL CHIP 0 5% 1/16W
R767 1-216-864-11 METAL CHIP 0 5% 1/16W
R801 1-216-833-11 METAL CHIP 10K 5% 1/16W
R802 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R803 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R804 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R805 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R806 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R807 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R808 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R809 1-216-801-11 METAL CHIP 22 5% 1/16W
R810 1-216-801-11 METAL CHIP 22 5% 1/16W
R811 1-216-801-11 METAL CHIP 22 5% 1/16W
R812 1-216-801-11 METAL CHIP 22 5% 1/16W
R813 1-216-801-11 METAL CHIP 22 5% 1/16W
R814 1-216-801-11 METAL CHIP 22 5% 1/16W
R815 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R816 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R817 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R818 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R819 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R820 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R821 1-216-801-11 METAL CHIP 22 5% 1/16W
R822 1-216-801-11 METAL CHIP 22 5% 1/16W
R823 1-216-801-11 METAL CHIP 22 5% 1/16W
R824 1-216-801-11 METAL CHIP 22 5% 1/16W
R825 1-216-801-11 METAL CHIP 22 5% 1/16W
R826 1-216-801-11 METAL CHIP 22 5% 1/16W
R827 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R834 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R840 1-216-833-11 METAL CHIP 10K 5% 1/16W
R841 1-216-833-11 METAL CHIP 10K 5% 1/16W
R842 1-216-807-11 METAL CHIP 68 5% 1/16W
R843 1-216-807-11 METAL CHIP 68 5% 1/16W
R844 1-216-807-11 METAL CHIP 68 5% 1/16W
R845 1-216-807-11 METAL CHIP 68 5% 1/16W
R846 1-216-807-11 METAL CHIP 68 5% 1/16W
R847 1-216-807-11 METAL CHIP 68 5% 1/16W
AV-071
