2-3-2 Bottom View
Fig. 2-10 Bottom Parts Location
1 GEAR JOINT 1
2 GEAR JOINT 2
3 BRAKET GEAR
4 ASS’Y MOTOR CAPSTAN
5 ASS’Y LEVER T LOAD
6 GEAR LOADING DRIVE
7 ASS’Y LEVER S LOAD
8 ASS’Y CLUTCH
9 BELT PULLEY
0 SLIDER CAM
