Sony RM-PJ25 - GB Board

1-13 (E)
VPL-HW40ES
1-3-12. GB Board
1 Four screws
(PSW3 x 8)
2 Shield (GB)
3 GB board
4 Shield (BLT)
CN201
CN202
CN203
CN302
CN303
CN301
When removing the GB board, remove it in the
way that the GB board should not contact with
the metal plate of the G board holder.
G board holder block
