2-13 (E)
VPL-HW40ES
External NVM
Memory : Save the Data from
CPU RAM to NVM
Initialize : Reset the Data to default value
Active memory copy : Load the Data from NVM to CPU RAM
External NVM CPU RAM
No.01
No.02
No.03
No.04
Status
Memory
No.120
Status Memory
Set MemorySet MemorySet Memory
2.
1.
No.01
No.02
No.03
No.04
No.99
No.101
Input-A
User
No.120
No.03
No.04
Component
Preset
No.99
No.03
No.04
Status
Memory
HDMI1
Preset
No.99
No.03
No.04
HDMI2
Preset
No.99
Input-A
Preset
This section explains the data streaming simply.
When the projector is turned on, required data for the
current picture, such as status memory data, etc., are se-
lected from the respective memory blocks, and are written
into the internal RAM. When adjustment is carried out,
adjustment data are written into the NVM automatically
(items on the user mode) or by the trigger of memory
operation (items on the service mode), then stored them.
Be careful that the factory preset (adjusted) data of the user
adjustable items are all eliminated from the memory when
user performs adjustment of the adjustable items (W/B and
Device Adjust) and the memory operation to memorize the
user adjustment data into the NVM.
* When the power to the projector is turned off without memorizing the
adjustment data, the original factory preset (adjusted) data can be
restored by removing the power cord once and connect it back again.
2-7. Memory
Memory structure consists of the following memory
blocks.
1. Set Memory
2. Status Memory
3. Video Memory
4. W/B Memory
5. Channel Memory
6. Installation Memory
7. Picture Memory
8. RCP Memory
9. FAN Memory
10. UF Memory
11. LUT Memory
12. Sub Micro Memory
13. Panel Alignment Memory
External NVM (EEPROM) : 256 kbit
