7. Diag (Wireless LAN Test)
This screen performs wireless LAN/Miracast test.
Screen 1: Selects the wireless LAN test category
Operation:
[B]/[b] Selects the category
[v]/[ ] Moves to the selected category
[BACK] Returns to the service top menu
Screen 2: Wireless LAN test
[1] Show WLAN HwInfo (Not used for the servicing)
[2] Connect to AccessPoint (Not used for the servicing)
[3] Start Display RSSI Value (Not used for the servicing)
[4] Start Ping Test (Not used for the servicing)
[5] Write P2P address to Registry
[6] P2P Registry Check
Operation:
[V]/[v] Selects the item
[ ] Executes the test
[BACK] Returns to selection of test category
Screen 2: Select [5] Write P2P address to Registry
• Viewing the display
P2P device address : xx:xx:xx:xx:xx:xx
When write P2P address to registry is OK: “Write Successful!” is
displayed
When write P2P address to registry is NG: “Write Fail!” is dis-
played
Screen 3: Select [6] P2P Registry Check
Check the P2P Registry address is the same as displayed in Screen
2.
8. Diag (Mic Test)
Note: Not used in this unit.
9. Diag (HDMI Input Test)
Note: Not used in this unit.
10. Diag (Transcoder Test)
Note: Not used in this unit.

Diag
(Screen 1)
(Screen 2)
Category: Wireless LAN Test
(Screen 3)
Diag
Category: Wireless LAN Test
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
P2P device address: 32:52:cb:15:e7:95
HELP: [UP] [DOWN] [ENT] [RET]
Status: Write Successful!
[1] Show WLAN HwInfo
[5] Write P2P address to Registry
[6] P2P Registry Check
Diag
Category: Wireless LAN Test
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
P2P device address: 32:52:cb:15:e7:95
HELP: [UP] [DOWN] [ENT] [RET]
[1] Show WLAN HwInfo
[5] Write P2P address to Registry
[6] P2P Registry Check
