11. Diag (Bluetooth Device Test)
This screen performs Bluetooth device test.
Screen 1: Selects the Bluetooth device test category
Operation:
[B]/[b] Selects the category
[v]/[ ] Moves to the selected category
[BACK] Returns to the service top menu
Screen 2: Bluetooth device test
(1) Bluetooth Enable
(2) Bluetooth Disable
(3) Write Bluetooth device address to Registry
(4) Bluetooth Inquiry Test (Not used for the servicing)
Operation:
[V]/[v] Selects the item
[ ] Executes the test
[BACK] Returns to selection of test category
Screen 2: Select (1) Bluetooth Enable
• Viewing the status display
OK: “Bluetooth Enable Successful!” is displayed
NG: “Bluetooth Enable Fail!” is displayed
Screen 3: Select (2) Bluetooth Disable
• Viewing the status display
OK: “Bluetooth Disable Successful!” is displayed
NG: “Bluetooth Disable Fail!” is displayed
Screen 4: Select (3) Write Bluetooth device address to
Registry
(Displayed characters/values in the following fi gure are example)
It records the address of the Bluetooth device.
• Viewing the status display
OK: “Write Successful!” is displayed
NG: “Write Fail!” is displayed
(Screen 3)
Diag
Diag
Category: Bluetooth Device Test
(2) Bluetooth Disable
(3) Write Bluetooth device address to Registry
(4) Bluetooth Inquiry Test
HELP: [UP] [DOWN] [ENT] [RET]
(Screen 1)
(Screen 2)
Category: Bluetooth Device Test
(1) Bluetooth Enable
Status: Bluetooth Enable Successful!
Diag
Category: Bluetooth Device Test
(3) Write Bluetooth device address to Registry
(4) Bluetooth Inquiry Test
HELP: [UP] [DOWN] [ENT] [RET]
(1) Bluetooth Enable
Status: Bluetooth Disable Successful!
(Screen 4)
Status: Write Successful!
Diag
Category: Bluetooth Device Test
(2) Bluetooth Disable
(3) Write Bluetooth device address to Registry
(4) Bluetooth Inquiry Test
Bluetooth Device address: 30:52:CB:15:E7:95
HELP: [UP] [DOWN] [ENT] [RET]
