2-16. RF MODULATOR BLOCK-2
• Continued on 2-17 (page 26).
– Rear view –
 +Rw WR iQVWaOO WKe VKeeW R
– 7RS view –
sheet (R)
1 cushion (H15)
1 cushion
(H15)
2 two canoe clips
(small)
2 two canoe clips
(small)
guide line
guide pin
groove
guide pin
groove
 3aVWiQJ SRViWiRQ RI WKe FXVKiRQ +
cushion (H15)
USB wire
cushion (H15)
Note 1:
Lay a soft piece of cloth
under the unit to avoid
damaging the grille assy.
3 sheet (R)
Note 2:
The sheet (R) is affixed
using adhesive sheet.
Right side
Top side
