2-29. LOUDSPEAKER (SP3, SP4) (R-ch)-1
• Continued on 2-30 (page 38).
– Right speaker block front view –
Right side
Top side
Left side
Bottom side
1 two screws
(3.5)
1 two screws
(3.5)
2 screw (3.5)
2 screw (3.5)
1 screw (3.5)
2 seven screws
(3.5)
1 screw
(3.5)
1 screw
(3.5)
1 screw
(3.5)
2
qg
qh
5
7
9
0
3
1
6
8
qd
4qa
qs
qj
qf
Note:
When installing screws, follow the installing procedure in the numerical order given.
