Sony SA-ST9 - Side Panel Section

74
HT-ST9
6-2. SIDE PANEL SECTION
• Rear bottom view
51 3-704-515-22 SCREW (BV/RING)
52 4-563-584-01 CUSHION (FOOT FRONT)
53 4-567-511-01 CUSHION (FOOT CENTER)
54 4-566-464-01 FOOT (Z)
55 X-2590-685-2 PANEL (SIDE R) ASSY (for R-ch)
56 X-2591-153-1 PANEL (SIDE L) ASSY (for L-ch)
57 4-571-335-01 CUSHION (ABSO PANEL SIDE)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
#2 7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
57
#2
#1
#2
#2
#2
#2
#2
not supplied
not supplied
not supplied
not supplied
not supplied
not supplied
not
supplied
not supplied
front block section
chassis section
56
51
52
52
54
53
51
51
51
54
51
51
51
51
51
51
51
51
51
51
51
51
55
57
not supplied
not supplied
#1
51
not supplied
not supplied
#2
#2
#2
#2
#2
not supplied
#2
#2
not supplied
#2
#2
#2
#2
#2
#2
Ver. 1.1
