Sony SA-ST9 - Diag (Wireless LAN Test)

HT-ST9
50
7. Diag (Wireless LAN Test)
This screen performs wireless LAN/Miracast test.
Screen 1: Selects the wireless LAN test category
Operation:
[
<
]/[
,
] Selects the category
[
m
]/[ ] Moves to the selected category
[BACK] Returns to the service top menu
Screen 2: Wireless LAN test
[1] Show WLAN HwInfo
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[5] Write P2P address to Registry
[6] P2P Registry Check
Operation:
[
M
]/[
m
] Selects the item
[ ] Executes the test
[BACK] Returns to selection of test category
Screen 2: Select [1] Show WLAN HwInfo
(Displayed characters/values in the following fi gure are example)
• Viewing the display
Serial : Serial number
Hard : Hardware version
Mac : Mac address
Screen 3: Select [2] Connect to AccessPoint
Connect access point only with the following AP settings.
CERT : NO-ENCRYPT
WEPKEY : abcdef1234
PMK : ABCDE12345
SSID : SONY-Test-R
IPADDR : 192.168.1.100
NETMASK : 255.255.255.0
BROADCAST : 192.168.1.10
When connect to AP, Status is “Connected!”
When cannot connect to AP, Status is “Can’t connect!”
Screen 4: Select [3] Start Display RSSI Value
(Displayed characters/values in the following fi gure are example)
RSSI value is displayed.
Screen 5: Select [4] Start Ping Test
Ping test is executed (IP address use the value of “192.168.1.10”).
OK: “192.168.1.10 OK!” is displayed
NG: “192.168.1.10 failed!” is displayed
Screen 6: Select [5] Write P2P address to Registry
• Viewing the display
P2P device address : xx:xx:xx:xx:xx:xx
When write P2P address to registry is OK: “Write Successful!” is
displayed
When write P2P address to registry is NG: “Write Fail!” is dis-
played
Screen 7: Select [6] P2P Registry Check
Check the P2P Registry address is the same as displayed in Screen
6.
(Screen 5)
(Screen 4)

Diag
 Diag
Category: Wireless LAN Test
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
Serial : 201407220100276
HELP: [UP] [DOWN] [ENT] [RET]
Hard : 18
Mac : ec:0e:c4:18:43:d1
(Screen 1)
(Screen 2)
Category: Wireless LAN Test
[1] Show WLAN HwInfo
[5] Write P2P address to Registry
[6] P2P Registry Check
 Diag
Category: Wireless LAN Test
RSSI Value: 0
HELP: [UP] [DOWN] [ENT] [RET]
 Diag
Category: Wireless LAN Test
Ping To 192.168.1.10
PING 192.168.1.10 OK!
HELP: [UP] [DOWN] [ENT] [RET]
(Screen 3)
 Diag
Category: Wireless LAN Test
[3] Start Display RSSI Value
[4] Start Ping Test
IPADDR: 192.168.1.100
HELP: [UP] [DOWN] [ENT] [RET]
NETMASK: 255.255.255.0
BROADCAST: 192.168.1.10
[1] Show WLAN HwInfo
CERT: NO-ENCRYPT
WEPKEY: abcdef1234
PMK: ABCDE12345
SSID: SONY-Test-R
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[1] Show WLAN HwInfo
[5] Write P2P address to Registry
[6] P2P Registry Check
[2] Connect to AccessPoint
[3] Start Display RSSI Value
[4] Start Ping Test
[1] Show WLAN HwInfo
[5] Write P2P address to Registry
[6] P2P Registry Check
[2] Connect to AccessPoint
Status: Conncted!
