PTZ TRACE Feature
You can record and play back up to eight different
operations of pan, tilt, and zoom to a maximum length of
180 seconds using the remote controller.
• No other operation can be performed during recording
playback.
• Since Positions 1 through 8 of the infrared remote
control are used for the record playback, be sure that
they do not overlap with preset functions.
• If you turn the PAN/TILT LIMIT from OFF to ON, the
stored operations will be cleared.
Perform PAN/TILT LIMIT first, then the record
operation.
• Please note that if you flip the image, the stored
operation will be cleared.
Recording pan/tilt/zoom operations
1
Press and hold the MENU button of the remote
controller for one second or longer to view the main
menu.
Using the joystick, move the cursor to select PTZ
TRACE. Press the top button on the joystick to open
the PTZ TRACE menu.
2
On the TRACE NO setting items in the PTZ TRACE
menu, move the joystick to select the number you
want to register.
TRACE NO will be the POSITION NO of the remote
controller during playback.
3
On the ACTION setting items, move the joystick to
select START POSITION SET.
Pressing the top button of the joystick allows you to
pan/tilt/zoom with the joystick. Press the top button
of the joystick again when the camera moves to the
initial position to start recording.
The initial position settings will be completed.
4
On the ACTION setting items, move the joystick
right or left to select RECORD/STOP.
The recording starts when you press the top button of
the joystick (the MENU screen does not turn off).
5
The REMAIN (SEC) countdown will start as well as
the recording of operation. The recording will be
finished when the count reaches 0 or you press the
button on the joystick again.
6
On the ACTION setting items, move the joystick
right or left to select PREVIEW.
You can review the recorded operation when you
press the top button of the joystick.
Playing back pan/tilt/zoom
operations
1
When the menu is not displayed, press the POSITION
NO button of the same number as the TRACE NO
you want to playback once.
Move to the playback start position.
2
When you press the same button again, the stored
playback of pan/tilt/zoom operation starts.
3
Press the HOME button during the recording
playback to end the playback immediately.
4
If you operate the joy stick during the record
playback, the playback will finish immediately and
then it follows the pan/tilt/zoom operation via the joy
stick.
There is no pause feature.
Deleting pan/tilt/zoom operations
1
Press and hold the MENU button of the remote
controller for one second or longer to view the main
menu.
Using the joystick, move the cursor to select PTZ
TRACE.
2
On the TRACE NO setting items in the PTZ TRACE
menu, move the joystick to select the number you
want to delete.
3
On the ACTION setting items, move the joystick
right or left to select DELETE.
The recording is deleted when you press the top
button of the joystick.
